Panasonic GD90 - 9 Replacement Parts List; Case Parts

REPLACEMENT PARTS LIST
MCUK990801C8 Section 9 Issue 1 Service Manual – 63 – Revision 0
D625 MAZS0750ML DIODE ZENER 7V5 SMD SS-MINI 2PIN F3
D627 MAZS0750ML DIODE ZENER 7V5 SMD SS-MINI 2PIN B1
D628 MAZS0750ML DIODE ZENER 7V5 SMD SS-MINI 2PIN A1
D629 MAZS0750ML DIODE ZENER 7V5 SMD SS-MINI 2PIN B1
E101 B9Z000000018 COUPLER 897.5 MHz SMD 2012 6PIN A4
E102 B9Z000000019 COUPLER 1.747GHz SMD 2012 6PIN A3
E600 JJ76002A CONNECTOR BATTERY 2 WAY SMD D1
E602 JJ76002A CONNECTOR BATTERY 2 WAY SMD C2
FL101 EFCH9017MTY1 FILTER SAW TX GSM/PCN SMD 3.8x3.8x1.6 B3
FL103 EXCML16A270U FILTER D4
FL104 EXCML16A270U FILTER B4
FL201 EFCH9418MTY2 FILTER SAW RX GSM/PCN SMD 3.8x3.8x1.6 A4
FL203 EFCH9418MTY2 FILTER SAW RX GSM/PCN SMD 3.8x3.8x1.6 E2
FL204 EFCH225MDQP1 FILTER IF SAW 225MHz SMD 7.2x5.2x1.8 E1
J502 K3ZZ00200009 HOLDER FOR BATTERY CELL F1
J601 JA76020B CONNECTOR SKT I/O 18 WAY SMD C3
L103 G1C6N8J00004 INDUCTOR 6.8nH 5% SMD 1005 B3
L105 G1C6N8J00004 INDUCTOR 6.8nH 5% SMD 1005 B3
L106 G1C22NJ00010 INDUCTOR 22nH 5% SMD 1005 B3
L107 G1C10NJ00008 INDUCTOR 10nH 5% SMD 1005 A3
L108 G1C15NJ00008 INDUCTOR 15nH 5% SMD 1005 B3
L111 G1C5N6Z00005 INDUCTOR 5.6nH +/-0.3nH SMD 1005 B3
L112 G1C3N3Z00005 INDUCTOR 3.3nH +/-0.3nH SMD 1005 A3
L150 G1C5N6Z00005 INDUCTOR 5.6nH +/-0.3nH SMD 1005 B4
L151 G1C12NJ00011 INDUCTOR 12nH 5% SMD 1005 B4
L191 G1C8N2J00002 INDUCTOR A3
L201 G1CR10J00010 INDUCTOR 100nH 5% SMD 1005 E1
L206 G1C12NJ00011 INDUCTOR 12nH 5% SMD 1005 E2
L207 G1C3N3Z00005 INDUCTOR 3.3nH +/-0.3nH SMD 1005 E2
L208 G1C56NJ00007 INDUCTOR 56nH 5% SMD 1005 E1
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
L209 G1C56NJ00007 INDUCTOR 56nH 5% SMD 1005 E1
L210 G1CR15J00003 INDUCTOR 150nH 5% SMD 1608 E1
L211 G1C68NJ00006 INDUCTOR 68nH 5% SMD 1608 E1
L212 G1CR10J00007 INDUCTOR 0.1uH 5% SMD 1608 E1
L213 G1C33NJ00009 INDUCTOR 33nH 5% SMD 1005 E1
L214 G1C82NJ00001 INDUCTOR 82nH 5% SMD 2125 D1
L215 G1C8N2J00004 INDUCTOR 8.2nH 5% SMD 1005 A4
L216 G1C33NJ00009 INDUCTOR 33nH 5% SMD 1005 A4
L217 G1C47NJ00010 INDUCTOR 47nH 5% SMD 1005 A4
L218 G1C22NJ00010 INDUCTOR 22nH 5% SMD 1005 A4
L219 G1C8N2J00004 INDUCTOR 8.2nH 5% SMD 1005 A4
L220 G1C6N8J00004 INDUCTOR 6.8nH 5% SMD 1005 A4
L221 G1C15NJ00008 INDUCTOR 15nH 5% SMD 1005 A4
L222 G1C10NJ00008 INDUCTOR 10nH 5% SMD 1005 A4
L230 G1C33NJ00009 INDUCTOR 33nH 5% SMD 1005 E1
L301 G1C22NJ00010 INDUCTOR 22nH 5% SMD 1005 B3
L303 G1C8N2J00004 INDUCTOR 8.2nH 5% SMD 1005 B4
L351 G1C1R2K00006 INDUCTOR 1.2uH 5% SMD 1608 C2
L501 G1A101C00002 INDUCTOR 100uH 30% 1.73 OHM 0.2A SMD E4
LS601 HB76004A BUZZER GD90 F2
P101 PY76011A G520 COAXIAL RF CONNECTOR
P603 PY76024A CONNECTOR
Q101 B1GKCFJJ0006 TRANSISTOR UMC3NTR PNP+NPN SMD UMT5/6 D2
Q102 B1GKCFJJ0006 TRANSISTOR UMC3NTR PNP+NPN SMD UMT5/6 E2
Q103 B1GKCFJJ0006 TRANSISTOR UMC3NTR PNP+NPN SMD UMT5/6 E1
Q104 B1GKCFLL0008 TRANSISTOR UMC2NTR PNP+NPN SMD UMT5/6 E1
Q105 UNR9213J0L TRANSISTOR UNR9213J0L E1
Q106 XP0338300L TRANSISTOR NPN/PNP DUAL S-MINI 5 TERMS B3
Q201 B1GKCFJJ0006 TRANSISTOR UMC3NTR PNP+NPN SMD UMT5/6 D3
Q301 B1GKCFJJ0006 TRANSISTOR UMC3NTR PNP+NPN SMD UMT5/6 C2
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
