Panasonic GD90 - Residual Peak Power

TECHNICAL SPECIFICATIONS
Issue 1 Section 5 MCUK990801C8
Revision 0 – 26 – Service Manual
5.1.6 Output Level, Dynamic Operation
GSM 900
GSM 1800
5.1.7 Residual Peak Power
≤70 dBc (BW = 300 kHz)
Power Control Level
Transmitter Output Power
(dBm)
Tolerance for Conditions (dB)
Normal Extreme
5 33 ±3 ±4
6 31 ±3 ±4
7 29 ±3 ±4
8 27 ±3 ±4
9 25 ±3 ±4
10 23 ±3 ±4
11 21 ±3 ±4
12 19 ±3 ±4
13 17 ±3 ±4
14 15 ±3 ±4
15 13 ±3 ±4
16 11 ±5 ±6
17 9 ±5 ±6
18 7 ±5 ±6
19 5 ±5 ±6
Power Control Level
Transmitter Output Power
(dBm)
Tolerance for Conditions (dB)
Normal Extreme
0 30 ±3 ±4
1 28 ±3 ±4
2 26 ±3 ±4
3 24 ±3 ±4
4 22 ±3 ±4
5 20 ±3 ±4
6 18 ±3 ±4
7 16 ±3 ±4
8 14 ±3 ±4
9 12 ±4 ±5
10 10 ±4 ±5
11 8 ±4 ±5
12 6 ±4 ±5
13 4 ±4 ±5
14 2 ±5 ±6
15 0 ±5 ±6
