REPLACEMENT PARTS LIST
Issue 1 Section 9 MCUK990801C8
Revision 0 – 64 – Service Manual
Q350 B1ABCB000024 TRANSISTOR 2SC4226 NPN SMD SOT323 C2
Q501 B1CFJC000001 TRANSISTOR DUAL FET N-CH SMD SC70-66 E4
Q502 2SD2216J-TX TRANSISTOR E3
Q503 B1DHDC000006 TRANSISTOR E3
Q504 B1GFCFNN0010 TRANSISTOR UMG2NTR NPN X 2 SMD UMT5/6 D3
Q505 2SD15110FL TRANSISTOR 2SD15110FL E1
Q510 B1ADPC000003 TRANSISTOR 2SB1424T100R PNP SMD SOT89 D3
Q600 B1GKGFBJ0001 TRANSISTOR IMD14 DUAL SMD SMT6 D1
Q601 B1GKGFBJ0001 TRANSISTOR IMD14 DUAL SMD SMT6 C2
Q602 B1GFCFNN0010 TRANSISTOR UMG2NTR NPN X 2 SMD UMT5/6 E4
Q603 YDTC123JETL TRANSISTOR 150MW 50V B1
Q604 B1GFCFNN0010 TRANSISTOR UMG2NTR NPN X 2 SMD UMT5/6 D3
R101 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 D1
R102 EXB24V392JX RES NETWORK 3.9K OHMx2 5% 1/16W SMD 1010 C2
R103 EXB24V392JX RES NETWORK 3.9K OHMx2 5% 1/16W SMD 1010 C2
R104 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 D2
R107 ERJ2GEJ223X CHIP RESISTOR 22K OHM +/-5% 1/16W SM 1005 C2
R108 ERJ2GEJ330X CHIP RESISTOR 33 OHM +/-5% 1/16W SM 1005 B4
R109 ERJ2GEJ561X CHIP RESISTOR 560 OHM +/-5% 1/16W SM 1005 B4
R111 ERJ2GEJ101X CHIP RESISTOR 100 OHM +/-5% 1/16W SM 1005 B4
R112 EXB24AT2AR3X ATTENUATOR B4
R115 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 B4
R117 EXB24AT2AR3X ATTENUATOR B3
R122 ERJ2GEJ470X CHIP RESISTOR 47 OHM +/-5% 1/16W SM 1005 A4
R123 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 B4
R132 ERJ2GEJ273X CHIP RESISTOR 27K OHM +/-5% 1/16W SM 1005 E1
R134 ERJ2GEJ122X CHIP RESISTOR 1K2 OHM +/-5% 1/16W SM 1005 E1
R135 ERJ2GEJ273X CHIP RESISTOR 27K OHM +/-5% 1/16W SM 1005 E1
R137 ERJ2GEJ122X CHIP RESISTOR 1K2 OHM +/-5% 1/16W SM 1005 E1
R141 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 A4
R144 ERJ2GEJ470X CHIP RESISTOR 47 OHM +/-5% 1/16W SM 1005 A3
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
R150 ERJ2GEJ820X CHIP RESISTOR 82 OHM +/-5% 1/16W SM 1005 A4
R151 ERJ2GEJ101X CHIP RESISTOR 100 OHM +/-5% 1/16W SM 1005 A4
R152 ERJ2GEJ820X CHIP RESISTOR 82 OHM +/-5% 1/16W SM 1005 A4
R153 ERJ2GEJ563X CHIP RESISTOR 56K OHM +/-5% 1/16W SM 1005 E4
R154 ERJ2GEJ563X CHIP RESISTOR 56K OHM +/-5% 1/16W SM 1005 A4
R155 ERJ2GEJ273X CHIP RESISTOR 27K OHM +/-5% 1/16W SM 1005 C4
R156 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 C4
R157 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C4
R158 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C4
R161 ERJ2GEJ273X CHIP RESISTOR 27K OHM +/-5% 1/16W SM 1005 C4
R162 ERJ2GEJ820X CHIP RESISTOR 82 OHM +/-5% 1/16W SM 1005 A3
R163 ERJ2GEJ101X CHIP RESISTOR 100 OHM +/-5% 1/16W SM 1005 A3
R164 ERJ2GEJ820X CHIP RESISTOR 82 OHM +/-5% 1/16W SM 1005 A3
R165 ERJ2GEJ681X CHIP RESISTOR 680 OHM +/-5% 1/16W SM 1005 C4
R166 ERJ2GEJ681X CHIP RESISTOR 680 OHM +/-5% 1/16W SM 1005 A4
R201 ERJ2GEJ222X CHIP RESISTOR 2K2 OHM +/-5% 1/16W SM 1005 E1
R202 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 D1
R203 EXB24V103JX RES NETWORK 10K OHMx2 5% 1/16W SMD 1010 D1
R208 ERJ2GEJ393X CHIP RESISTOR 39K OHM +/-5% 1/16W SM 1005 A4
R210 EXB24AT1AR3X ATTENUATOR E1
R220 ERJ2GEJ471X CHIP RESISTOR 470 OHM +/-5% 1/16W SM 1005 A4
R302 ERJ2GEJ182X CHIP RESISTOR 1K8 OHM +/-5% 1/16W SM 1005 B4
R303 ERJ2GEJ472X CHIP RESISTOR 4K7 OHM +/-5% 1/16W SM 1005 C4
R304 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 C4
R305 ERJ2GEJ150X CHIP RESISTOR 15 OHM +/-5% 1/16W SM 1005 C4
R309 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 C3
R309 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 E3
R310 ERJ2GEJ222X CHIP RESISTOR 2K2 OHM +/-5% 1/16W SM 1005 C3
R311 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 C3
R312 ERJ2GEJ270X CHIP RESISTOR 27 OHM +/-5% 1/16W SM 1005 C3
R317 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 B3
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
