REPLACEMENT PARTS LIST
MCUK990801C8 Section 9 Issue 1 Service Manual – 65 – Revision 0
R318 ERJ2GEJ560X CHIP RESISTOR 56 OHM +/-5% 1/16W SM 1005 B3
R319 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C2
R319 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 E4
R322 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 D1
R323 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 D4
R324 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 D1
R350 ERJ2GEJ472X CHIP RESISTOR 4K7 OHM +/-5% 1/16W SM 1005 D4
R351 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C2
R352 ERJ2GEJ221X CHIP RESISTOR 220 OHM +/-5% 1/16W SM 1005 C2
R353 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C2
R354 ERJ2GEJ223X CHIP RESISTOR 22K OHM +/-5% 1/16W SM 1005 C2
R355 ERJ2GEJ681X CHIP RESISTOR 680 OHM +/-5% 1/16W SM 1005 C2
R356 ERJ2GEJ682X CHIP RESISTOR 6K8 OHM +/-5% 1/16W SM 1005 C2
R357 ERJ2GEJ101X CHIP RESISTOR 100 OHM +/-5% 1/16W SM 1005 C2
R501 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 E3
R503 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 E4
R504 ERJ2GEJ473X CHIP RESISTOR 47K OHM +/-5% 1/16W SM 1005 E3
R505 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E3
R506 ERJ6GEYJ330V RES 33 OHM 5% 1/10W SMD 2012 E3
R507 ERJ2GEJ153X CHIP RESISTOR 15K OHM +/-5% 1/16W SM 1005 E3
R508 ERJ2GEJ123X CHIP RESISTOR 12K OHM +/-5% 1/16W SM 1005 E3
R510 ERJ6RSFR15V CHIP RESISTOR 0R15 OHM +/-5% 1/10W SM 2012 E3
R511 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 F3
R512 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E3
R513 ERJ2GEJ105X RES 1M OHM 5% 1/16W SMD 1005 E4
R514 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E3
R515 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E3
R516 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 E4
R517 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 E3
R521 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 E4
R522 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 E3
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
R530 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005
R531 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005
R532 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005
R533 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E4
R534 ERJ2GEJ222X CHIP RESISTOR 2K2 OHM +/-5% 1/16W SM 1005 B1
R535 ERJ2GEJ472X CHIP RESISTOR 4K7 OHM +/-5% 1/16W SM 1005 B1
R547 ERJ2GEJ222X CHIP RESISTOR 2K2 OHM +/-5% 1/16W SM 1005 F1
R548 ERJ2GEJ393X CHIP RESISTOR 39K OHM +/-5% 1/16W SM 1005 F1
R602 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 C1
R603 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 E4
R604 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 D3
R605 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 D4
R606 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 C1
R610 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 C1
R611 ERJ6GEYJ560V RES 56 OHM 5% 1/10W SMD 2012 D1
R612 ERJ6GEYJ270V RES 27 OHM 5% 1/10W SMD 2012 C2
R613 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C1
R614 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 C1
R615 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E4E
R616 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E4
R619 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005
R623 ERJ2GEJ152X CHIP RESISTOR 1K5 OHM +/-5% 1/16W SM1005 D4
R624 ERJ2GEJ152X CHIP RESISTOR 1K5 OHM +/-5% 1/16W SM1005 D4
R625 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 D4
R626 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 D4
R635 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 A2
R637 ERJ2GEJ332X CHIP RESISTOR 3K3 OHM +/-5% 1/16W SM1005 E4
R638 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 E4
R639 ERJ2GEJ681X CHIP RESISTOR 680 OHM +/-5% 1/16W SM 1005 E4
R640 ERJ2GEJ472X CHIP RESISTOR 4K7 OHM +/-5% 1/16W SM 1005 B1
R641 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 B1
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
