REPLACEMENT PARTS LIST Issue 1 Section 9 MCUK990801C8 Revision 0 – 66 – Service Manual
R642 ERJ2GEJ104X CHIP RESISTOR 100K OHM +/-5% 1/16W SM 1005 D3
R643 ERJ2GEJ561X CHIP RESISTOR 560 OHM +/-5% 1/16W SM 1005 E4
R648 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 D4
R649 ERJ2RKF104X CHIP RESISTOR 100K OHM 1005 +/-1% 1/16W A1
R650 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 C2
R651 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 A1
R652 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 B1
R653 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 E4
R654 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 E4
R655 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 B1
R656 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 D1
R657 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 B1
R658 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 B1
R659 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 A1
R660 ERJ2GEJ331X CHIP RESISTOR 330 OHM +/-5% 1/16W SM 1005 F3
R661 ERJ2GEJ103X CHIP RESISTOR 10K OHM +/-5% 1/16W SM 1005 F3
S101 SY76003A DIPLEXER ANTENNA SWITCH GSM/DSC SMD A4
U101 C1CB00000803 IC HD155123FEB RF BRIGHT 2 GSM/PCN SMD E1
U102 UY76044A VCO TX SMD 9.3x7.2x2.0 C4
U103 C1CB00000794 IC MGA-81563-1HA MMIC AMP SMD SOT363 B3
U104 C5CB00000023 PA PF08103B-02-TB DUAL GSM/DCS SMD B3
U150 C1CB00000711 IC DUAL BAND APC TSSOP20 C4
U203 GN01073B01MC LNA DUAL GSM/DCS SMD 0.65mm PITCH S06 A4
U301 C1CB00000795 IC C3
U302 UY76043A VCO RF SMD 9.3x7.2x2.0 B4
U303 UY76084A VCO IF DUAL 520/540MHz SMD 5.3x5.0x2.0 C3
U350 TX76001A TCVCXO 13MHz SMD 7.0x5.0x1.7 4PIN C4
U401 C0DBZFC00004 IC D1
U506 UY76046A IC BH6107KV INTERFACE ASIC SMD QFP48 E4
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
U507 UY76051A IC BA3891KV CHARGE ASIC SMD QFP48 E3
U508 C0DBFGG00001 IC R5102V001A-E2 REG WDT SMD SSOP10 D3
U509 C0DBAFC00007 IC R1111N181B REG 1.8V SMD SOT23-5 C1
U510 C0EBD0000030 IC S-80824ANNP-EDM-T2 VOL DET 2.4V SMD C1
U602 UY76085A IC D4
U604 YRS5C348A IC RS5C348A REAL TIME CLOCK SMD SSOP10 C1
X601 JS8A00005 G600 SIM HOLDER A2
Y601 H0J327200022 CRYSTAL 32.768KHz SMD 7.0x1.5x1.4 D3
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
