REPLACEMENT PARTS LIST
MCUK990801C8 Section 9 Issue 1 Service Manual – 67 – Revision 0
9.3.3 Keypad PCB
Model: EB-GD90 Name: Keypad PCB
Ref: Part Number Description Grid
C701 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 D4
C702 F1J1A1050011 CAP CER 1µF 10% 10V SMD X5R 2012 D4
C703 F1J1A1050011 CAP CER 1µF 10% 10V SMD X5R 2012 D4
C704 F1J1A1050011 CAP CER 1µF 10% 10V SMD X5R 2012 D4
C705 F1J1A1050011 CAP CER 1µF 10% 10V SMD X5R 2012 D4
C706 F1H1A224A006 CAP CER 220nF 10% 10V SMD 1608 D4
C707 F1H1A224A006 CAP CER 220nF 10% 10V SMD 1608 D4
C708 F1H1A224A006 CAP CER 220nF 10% 10V SMD 1608 D3
C709 F1H1A224A006 CAP CER 220nF 10% 10V SMD 1608 D3
C710 F1H1A224A006 CAP CER 220nF 10% 10V SMD 1608 D3
C712 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 F3
C734 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 F4
C735 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 F4
D722 MA2S11100L DIODE 80V 100MA SMD SS-M1W1 2 PIN F3
D724 MAZS0750ML DIODE ZENER 7V5 SMD SS-MINI 2PIN D3
D726 MAZS0470GL DIODE MAZS0470G ZENER 4.7V SMD SS-MINI F4
D727 MAZS0470GL DIODE MAZS0470G ZENER 4.7V SMD SS-MINI F4
D729 MAZS0470GL DIODE MAZS0470G ZENER 4.7V SMD SS-MINI F3
DS701 LNJ115W8PRA LED F3
DS702 LNJ115W8V0MC LED D3
DS703 LNJ115W8V0MC LED D4
DS705 LNJ312G8J0MC LED C4
DS706 LNJ312G8J0MC LED D3
DS707 LNJ312G8J0MC LED C4
DS708 LNJ312G8J0MC LED D3
DS709 LNJ312G8J0MC LED B4
DS710 LNJ312G8J0MC LED D3
DS711 LNJ312G8J0MC LED A4
DS712 LNJ312G8J0MC LED D3
L701 HK100582NJT INDUCTOR 82nH 5% SMD 1005 F4
L702 HK100582NJT INDUCTOR 82nH 5% SMD 1005 F4
P702 PY76003A CONNECTOR D3
R702 ERJ3RED274V RES D3
R703 ERJ3RED105V RES D3
R711 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 F3
R731 ERJ2GEJ120X CHIP RESISTOR 12 OHM +/-5% 1/16W SM 1005 F4
R732 ERJ2GEJ120X CHIP RESISTOR 12 OHM +/-5% 1/16W SM 1005 F4
R741 ERJ2GEJ101X CHIP RESISTOR 100 OHM +/-5% 1/16W SM 1005 F4
R742 ERJ2GEJ101X CHIP RESISTOR 100 OHM +/-5% 1/16W SM 1005 F4
R749 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R750 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R751 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D4
R752 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D4
R753 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 F3
R754 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R755 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R756 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R757 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R758 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D4
R759 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D4
R760 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D3
R761 ERJ2GEJ181X CHIP RESISTOR 180 OHM +/-5% 1/16W SM 1005 D4
R771 ERJ2GE0R00X RES JUMPER 0 OHM 1A SMD 1005 F4
S722 EVQPSR02K SWITCH TACTILE F3
