Panasonic GD90 - Rx Characteristics

TECHNICAL SPECIFICATIONS
MCUK990801C8 Section 5 Issue 1
Service Manual – 27 – Revision 0
5.2 Rx Characteristics
5.2.1 Sensitivity
GSM 900 Full rate speech
The reference sensitivity performance in terms of frame erasure, bit error, or residual bit error rates (whichever is
appropriate) is specified in the following table, according to the propagation conditions.
The reference sensitivity level is <-102dBm.
NOTE: 1 ≤ α ≤ 1.6. The value of a can be different for each channel condition but must remain the same for FER and
class Ib RBER measurements for the same channel condition.
GSM 900 Half rate speech
The reference sensitivity performance in terms of frame erasure, bit error, or residual bit error rates (whichever is
appropriate) is specified in the following table, according to the propagation conditions.
GSM 1800 Full rate speech
The reference sensitivity performance in terms of frame erasure, bit error, or residual bit error rates (whichever is
appropriate) is specified in the following table, according to the propagation conditions.
The reference sensitivity level is <-102 dBm.
NOTE: 1 ≤ α ≤ 1.6. The value of a can be different for each channel condition but must remain the same for FER and
class Ib RBER measurements for the same channel condition.
Channels
Propagation Conditions
TUhigh
Propagation Conditions
RA
Propagation Conditions
HT
Static Conditions
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
TCH/FS FER 6.742*α 8900 0.122*α 164000
class Ib (RBER) 0.42/α 1,000,000 0.41/α 20,000,000
class II (RBER) 8.33 120,000 7.5 24000 9.333 60000 2.439 8200
Channels
Propagation Conditions
TUhigh
Propagation Conditions
RA
Propagation Conditions
HT
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
TCH/HS (FER) 4.598 13050
TCH/HS class Ib (BFI=0) 0.404 148500
TCH/HS class II (BFI=0) 7.725 25500 8500 20000 7600 20000
TCH/HS (UFR) 6.250 9600
TCH/HSL class Ib ((BFI or UFI)=0) 0.269 227000
Channels
Propagation Conditions
TUhigh
Propagation Conditions
RA
Propagation Conditions
HT
Static Conditions
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
Test limit
error rate
%
Minimum
no. of
samples
TCH/FS FER 4.478*α 13400 0.122*α 164000
class Ib (RBER) 0.32/α 1,500,000 0.41/α 20,000,000
class II (RBER) 8.333 60,000 7.5 24000 9.333 30000 2.439 8200
