5 TECHNICAL SPECIFICATIONS
5.1 Tx Characteristics
All data is applicable to GSM900 and GSM1800 except where stated.
5.1.1 Frequency error
±0.1ppm max., relative to base station frequency.
5.1.2 Modulation phase error
RMS: ≤5°
Peak: ≤20°
5.1.3 Output RF Spectrum due to Modulation
5.1.4 Output RF Spectrum due to Switching Transients
Measurement conditions for output RF spectrum measurements:
Frequency Span: 0 Hz
Measurement Bandwidth: 30 kHz
Video Bandwidth: 100 kHz
Peak Hold
5.1.5 Spurious Emissions at the Antenna Connector
Measurement conditions:
Peak Hold, Modulated Carrier
a. Measurement averaged over a burst and then averaged again over 50 bursts.
b. In each of the bands 925-960 MHz and 1805-1880 MHz up to five spurious measurements can fail these limits, in which
case the limit ≤ -36dBm shall apply.
Offset from Centre Frequency (kHz) Maximum Level Relative to the Carrier (dB)
±100
±200
±250
±600 to 1800
+0.5
-30
-33
-60
Offset from Centre Frequency (kHz) Maximum Level (dBm)
GSM 900 GSM 1800
±400 -19 -22
±600 -21 -24
±1200 -21 -24
±1800 -24 -27
Frequency Range Frequency Offset Filter Bandwidth
Approximate Video
Bandwidth
Limits (dBm)
GSM 900 GSM 1800
30 to 50 MHz - 10 kHz 30 kHz -36 -36
50 to 500 MHz - 100 kHz 300 kHz -36 -36
500 MHz to 1GHz 0 to 1MHz 100 kHz 300 kHz -36 -36
1 GHz to 4GHz
Excl. relevant TX band:
P-GSM: 890 to 915 MHz;
DCS: 1710 to 1785 MHz
0 to 10 MHz
≥ 10 MHz
≥ 20 MHz
(offset from edge of
relevant TX band)
100 kHz
300 kHz
1 MHz
300 kHz
1 MHz
3 MHz
-30
-30
-30
-36
-36
-36
Relevent TX band:
P-GSM: 890 to 915 MHz;
DCS: 1710 to 1785 MHz
1.8 to 6.0 MHz
(offset from carrier)
30 kHz 100 kHz -30 -30
