Panasonic GD90 - 8 Layout Diagrams; Main PCB

REPLACEMENT PARTS LIST
MCUK990801C8 Section 9 Issue 1 Service Manual – 61 – Revision 0
C330 F1G1H3R0A442 CAP CER 3pF +/-0.25pF 50V SMD 1005 B4
C332 F1G1H3R0A442 CAP CER 3pF +/-0.25pF 50V SMD 1005 C3
C333 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 C4
C350 ECUE1H151JCQ CAP CER 150pF 5% 50V NP0 SMD 1005 C2
C351 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 C2
C352 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1005 D4
C353 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 C2
C355 ECUE1E102KBQ CAP CER 1nF 10% 25V X7R SMD 1005 C2
C356 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1005 C2
C357 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1005 C2
C358 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1005 C2
C359 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1005 C2
C360 ECUE1E271KBQ CAP CER 270pF 10% 25V X7R SMD 1005 C2
C361 ECUE1C103KBQ CAP CER 10nF 10% 16V X7R SMD 1005 C2
C363 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 D4
C401 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 D1
C402 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 D1
C403 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 D1
C404 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 D1
C405 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 D1
C406 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 D1
C407 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 D1
C408 F3F1A1560001 CAP TANT 15µF 20% 10V SMD C3
C409 F1G1H3R0A442 CAP CER 3pF +/-0.25pF 50V SMD 1005 D1
C411 F1G1H3R0A442 CAP CER 3pF +/-0.25pF 50V SMD 1005 D1
C412 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 D1
C505 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 E3
C506 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 E3
C510 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 E3
C511 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 E3
C512 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 E4
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
C514 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 E4
C515 F3F1A1560001 CAP TANT 15µF 20% 10V SMD E4
C516 F3E1A2250001 CAP E4
C517 F1G1H820A016 CAP CER 82pF 5% 50V SMD 1005 F4
C518 F1G1H150A409 CAP CER 15pF +1-5% 50V SMD 1005 F4
C519 F1G1H820A016 CAP CER 82pF 5% 50V SMD 1005 C1
C520 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 B1
C521 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 B1
C523 F1G1A4740002 CAP CER 470nF +80-20% 10V SMD 1005 E1
C524 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 E4
C525 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 E3
C526 F3F1A1560001 CAP TANT 15µF 20% 10V SMD D3
C527 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 E3
C528 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 E3
C529 F3E1A1050002 CAP E3
C530 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 C1
C531 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 F1
C532 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 C1
C533 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 F2
C534 F1G1H101A016 CAP CER 100pF +/-5% 50V SMD 1005 F2
C537 F1G1H3R0A442 CAP CER 3pF +/-0.25pF 50V SMD 1005 E3
C538 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 E3
C539 F3E0J1060005 CAP TANT 10µF 20% 6.3V SMD 2012 C1
C601 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 C1
C602 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 B2
C603 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 B1
C604 F1G0J1050001 CAP CER 1µF +80-20% 6.3V SMD 1005 B1
C607 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 C2
C608 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 C2
C609 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 C1
C610 ECUE1C104ZFQ CAP CER 0.1µF +80-20% 16V Y5V SMD 1005 C2
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
