REPLACEMENT PARTS LIST
MCUK990801C8 Section 9 Issue 1 Service Manual – 59 – Revision 0
9.3 Handheld Replacement Parts List
9.3.1 Main PCB Variants
9.3.2 Main PCB Components
Part No. Description
GD90BRD001 GD90 MAIN PCB ASSEMBLY STANDARD PROGRAM
GD90BRD002 GD90 MAIN PCB ASSEMBLY BINARING PROGRAM
GD90BRD003 GD90 MAIN PCB ASSEMBLY CELCOM PROGRAM
GD90BRD004 GD90 MAIN PCB ASSEMBLY AIRTEL PROGRAM
GD90BRD005 GD90 MAIN PCB ASSEMBLY EUROTEL PROGRAM
GD90BRD006 GD90 MAIN PCB ASSEMBLY MOVISTAR PROGRAM
GD90BRD007 GD90 MAIN PCB ASSEMBLY S.F.R PROGRAM
GD90BRD008 GD90 MAIN PCB ASSEMBLY WESTEL PROGRAM
GD90BRD009 GD90 MAIN PCB ASSEMBLY HUTCHISON PROGRAM
GD90BRD010 GD90 MAIN PCB ASSEMBLY PLUS GSM PROGRAM
GD90BRD011 GD90 MAIN PCB ASSEMBLY TURKCELL PROGRAM
GD90BRD012 GD90 MAIN PCB ASSEMBLY FRANCETEL PROGRAM
GD90BRD013 GD90 MAIN PCB ASSEMBLY FT FTMS PROGRAM
GD90BRD014 GD90 MAIN PCB ASSEMBLY TELESTET PROGRAM
GD90BRD015 GD90 MAIN PCB ASSEMBLY ACTIVA PROGRAM
GD90BRD016 GD90 MAIN PCB ASSEMBLY TMN PROGRAM
GD90BRD017 GD90 MAIN PCB ASSEMBLY PANNON PROGRAM
GD90BRD018 GD90 MAIN PCB ASSEMBLY VODACOM PROGRAM
GD90BRD019 GD90 MAIN PCB ASSEMBLY NRTCOM PROGRAM
GD90BRD020 GD90 MAIN PCB ASSEMBLY K.P.N PROGRAM
GD90BRD021 GD90 MAIN PCB ASSEMBLY MOBILCOM PROGRAM
GD90BRD022 GD90 MAIN PCB ASSEMBLY TELSTRA PROGRAM
GD90BRD023 GD90 MAIN PCB ASSEMBLY E.R.A PROGRAM
Model: EB-GD90 Name: Main PCB
Ref: Part Number Description Grid
C102 ECUE1E102KBQ CAP CER 1nF 10% 25V X7R SMD 1005 D1
C103 ECUE1H151JCQ CAP CER 150pF 5% 50V NP0 SMD 1005 D1
C104 ECUE1H151JCQ CAP CER 150pF 5% 50V NP0 SMD 1005 C2
C105 ECUE1E152KBQ CAP CER 1.5nF 10% 25V X7R SMD 1005 B4
C106 F1G1C2230001 CAP CER 22nF 10% 16V SMD 1005 B4
C110 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 E2
C111 F1G1H100A406 CAP CER 10pF +1-0.5pF 50V SMD 1005 E2
C112 F1G0J1040003 CAP CER 0.1µF 10% 6.3V SMD 1005 C2
C114 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 E2
C116 F1G0J1040003 CAP CER 0.1µF 10% 6.3V SMD 1005 C2
C119 F1G1H5R0A404 CAP CER 5pF +/-0.25pF 50V SMD 1005 B3
C120 F1G1H5R0A404 CAP CER 5pF +/-0.25pF 50V SMD 1005 B3
C124 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 B3
C125 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 B3
C126 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 B3
C129 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 B3
C130 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 B4
C131 F3F1A1560001 CAP TANT 15µF 20% 10V SMD E2
C132 F1G1H3R0A442 CAP CER 3pF +/-0.25pF 50V SMD 1005 A3
C133 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 B3
C134 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 A3
C135 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 B4
C136 F3F1A1560001 CAP TANT 15µF 20% 10V SMD B3
C137 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 A4
C138 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 A4
C139 F1G1H270A409 CAP CER 27pF +1-5% 50V SMD 1005 A3
C140 ECUE1E102KBQ CAP CER 1nF 10% 25V X7R SMD 1005 B4
C142 F1G1H220A409 CAP CER 22pF 5% 50V SMD 1005 A3
C143 F1G1H470A409 CAP CER 47pF 5% 50V SMD 1005 F1
