Panasonic JS-970 Series User Manual

24
Names of Parts and Their Functions
No. Name Functions Remarks
HDD Status LED Flashes yellow or green: Accessing HDD
Common to
WS / WP
Power Status
LED
Lights yellow or green: Operating
Lights red: Power off
Flashes yellow or green: Standby
Flashes red: Suspended
Common to
WS / WP
Display Unit
The unit which includes the operator’s
display and the main block.
Common to
WS / WP
Hinge Unit
A mechanism allowing the display unit to
be moved up / down (up to 70 degrees
above / below the horizontal) or side to
side (up to 15 degrees towards right / left)
WS only
Main Block
This unit contains the I/O port and the
storage unit.
Common to
WS / WP
Stand Unit This unit contains an AC adaptor. WS only
Rear Cover
Cover of the rear part of the stand unit.
Open when installing the 2nd display unit
or the rear display unit.
WS only
Main Cable Cover
Covers for protecting the cables
connected to the main block.
Common to
WS / WP
Base Cable Cover WS only
AC Inlet Connect the AC cord. WS only
POP Holder Used for POP advertising holder. WS only
Speaker Used for playing sound.
Common to
WS / WP
USB Cover
Used for protecting any USB port that
is used temporarily such as during
maintenance.
Common to
WS / WP
Base Cable Cover
Lock Lever
Used for releasing the base cable cover. WS only
