37
Operator’s Display Replacement
Be sure to disconnect the power cable of the main block (POS Workstation) and
confirm the power is “OFF” before the operation below.
■ When fixing parts that use VESA mounts are not installed
1
Follow step 1 in “AC Adapter Installation” to remove
the cable cover. (
page 28)
2
Loosen two thumbscrews securing the main block
and the operator’s display.
●
Loosen the thumbscrews until they are extended
by their springs.
●
If you continue to loosen the thumbscrews further
after they are extended, they could become
detached. Make sure not to detach them.
Thumbscrews
3
Hold both sides of the display unit and slowly
separate the main block from the operator’s display.
English
To Next Page
