34
Display Unit (Including Main Block) Replacement
3
Loosen and remove two thumbscrews securing the
cable clamps.
●
Be careful to keep the thumbscrews from falling
when you remove them.
4
Slide the display unit upward until the engagement
section of the display unit is disengaged, and then
pull it to remove from the stand section.
