1.13 P
236 Feature Manual
[CO Line Call to an Extension Not Answered, Forwarded to Mailbox (Extension Number Method)]
[Explanation]
Extension 201 does not answer the CO line call, so the call is forwarded to the VPS, and answered by
mailbox 201. If the outside caller leaves a message, the VPS sends a Message Waiting notification to the
extension using Enhanced QSIG information over the private network.
When forwarding the call, PBX-2 sends any received call information (Caller ID number/name, etc.) along
with the VM trunk group number to use, applicable time mode, and extension number and forwarding reason
of the original destination extension to PBX-1 as Enhanced QSIG information.
PBX-1
TIE Line Network
Private network
PBX-2
Outside Caller
PBX-3
PBX-4
PBX-5
PBX-6
PBX-7
Telephone Company
Extn. 201
Fwd to VPS
PBX-8
Extn.
101
Extn.
202
VPS
Mailbox 101
Mailbox 201
Mailbox 202
Mailbox 201:
"Hello. I am not at
my desk right now."
To Next Page
