Panasonic KX-UTG200

Element Available Value Description
Macro Timer T, t Example: "1x.T"
If the dialed phone number begins with "1", the call is made
after a lapse of "T" seconds.
• The value of "T" or "t" can be configured through the Web
user interface (® see [Timer for Dial Plan] in
4.6.1.1 Call Control).
Reject ! Example: "123xxx!"
If the dialed phone number is "123" followed by 3 digits, the
call is not made.
Alternation | Example: "1xxxx|2xxx"
If the dialed phone number is "1" followed by 4 digits, or "2"
followed by 3 digits, the call is made immediately.
You can use this element to specify multiple numbers.
Note
• You can enter up to 1024 characters in [Dial Plan].
• You can assign up to 128 dial plans separated by "|" in [Dial Plan].
• You can assign up to 1024 digits per dial plan in [Dial Plan].
• After the user completes dialing, the unit immediately sends all the dialed digits if [Call Even If Dial
Plan Does Not Match] is set to [Yes] in the Web user interface or if
"DIAL_PLAN_NOT_MATCH_ENABLE" is set to "N" in a configuration file. The unit recognizes the end
of dialing as follows:
– The inter-digit timer expires (® see [Inter-digit Timeout] in 4.6.1.1 Call Control in the Web user
interface or "INTDIGIT_TIM" in 5.5.1 Call Control Settings in the configuration file).
– The user presses [ENTER] or the # key.
– The call is initiated after going off-hook (pre-dial).
Dial Plan Example
The following example shows dial plans containing character sequences separated by "|".
Example: "[2346789]11|01[2-9]x.|[2-9]xxxxxxxxx"
Complete Match:
Example: "[2346789]11|01[2-9]x.|[2-9]xxxxxxxxx"
• If the dialed phone number is "211", "911" and so on, the call is made immediately.
Example: "[2346789]11|01[2-9]x.|[2-9]xxxxxxxxx"
• If the dialed phone number is "2123456789", "5987654321" and so on, the call is made immediately.
Partial Match (when the dial plan contains "."):
Example: "[2346789]11|01[2-9]x.|[2-9]xxxxxxxxx"
• If the dialed phone number is "01254", "012556" and so on, the call is made after the inter-digit timer expires.
Partial Match (when the dial plan does not contain "."):
Example: "[2346789]11|01[2-9]x.|[2-9]xxxxxxxxx"
• If the dialed phone number is "21", "91" and so on when [Call Even If Dial Plan Does Not Match] is set
to [Yes], the call is made after the inter-digit timer expires.
• If the dialed phone number is "21", "91" and so on when [Call Even If Dial Plan Does Not Match] is set
to [No], the call is denied after the inter-digit timer expires.
Document Version 2014-05 Administrator Guide 323
6.2.1 Dial Plan Settings
