Panasonic Lumix DC-GX9 User Manual

118
Focus, Brightness (Exposure) and Colour tone Settings
Adjusting the White Balance
Performing White Balance fine adjustments
White Balance settings can be individually fine-tuned if colours still do not appear as
anticipated.
1
In step
2
of “Adjusting the White Balance” (→116),
select the White Balance and press
2
Use to perform White Balance fine
adjustments
: A (amber: orangish colours)
: B (blue: bluish colours)
: G (green: greenish colours)
: M (magenta: reddish
colours)
• You can also make fine adjustments by touching the White
Balance graph.
• Pressing [DISP.] button resets the position back to the centre.
3
Press [MENU/SET] to finalise the setting
• Press the shutter button halfway to return to the recording
screen.
●
When you perform fine adjustments of the White Balance toward the A (amber) or B (blue) side,
the colour of the White Balance icon displayed on the screen will change to the fine-tuned colour.
●
When you perform fine adjustments of the White Balance toward the G (green) or M (magenta)
side, [+] (green) or [-] (magenta) will be displayed in the White Balance icon on the screen.

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
