Panasonic Lumix DC-GX9 User Manual

315
Others
List of monitor/viewfinder displays
• The following images are examples of when [Monitor Disp. Set] is set to [ ] (monitor
style) in the monitor.
• The information displayed, such as histograms, magnifications, and numeric values, are
only for the purpose of reference.
In recording
Recording mode (→47)
Custom Set (→93)
[Photo Style] (→192)
Flash setting
(→163, 164, 166, 169)
50p
Extra Tele Conversion (when
recording motion pictures)
(→156)
50p
[Rec Format]/[Rec Quality]
(→173)
[Snap Movie] (→177)
[Aspect Ratio] (→189)/
[Picture Size] (→190)
Extra Tele Conversion (when
taking still pictures) (→156)
Image size (Panorama Shot
Mode) (→76)
Picture effect (Filter)
adjustment display (→84, 194)
Types of picture effects (Filter)
(→194)
[Loop Recording(4K PHOTO)]
(→123)
Card (displayed only during
recording) (→33)
XXmXXs
Elapsed recording time
*
1
(→171)
Simultaneous recording
indicator (→176)
Automatic switching between
viewfinder and monitor (→45)
[Peaking] (→215)
[Highlight Shadow] (→197)
[HDR] (→203)/[iHDR] (→67)
[Multi Exp.] (→204)
[Digital Zoom] (→158)
Electronic shutter (→201)
Picture-taking during motion
picture recording (Photo
Priority) (→176)
Overheat indicator (→326)
50
p

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
