Panasonic Lumix DC-GX9 User Manual

36
Preparations
Attaching/Removing the Lens
• Check that the camera is turned off.
• When attaching or detaching the interchangeable lens (H-FS12032/H-FS35100), retract
the lens barrel.
• Change lenses where there is not a lot of dirt or dust. Refer to (→334) when dirt or dust
gets on the lens.
■
Attaching the lens
• When a lens rear cap is attached to the lens, detach it.
• When a body cap is attached to the camera, detach it.
Align the lens fitting marks ( ) and then rotate the lens in the direction of the arrow
until it clicks
• Do not press the lens release button ( ) when you attach a lens.
• Do not try to attach the lens when holding it at an angle to the camera body as the lens mount
may get scratched.

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
