Panasonic Lumix DC-GX9 User Manual

39
Preparations
Attaching/Removing the Lens
Temporarily Storing the Lens Hood
When using the interchangeable lens (H-FS35100/H-FS12060)
Turn the lens hood in the direction of the arrow to detach it
Align the mark ( ) ( ) on the lens hood with the mark on the tip of the lens
Turn the lens hood in the direction of the arrow until it clicks into place
When using the interchangeable lens (H-FS1442A/H-FS14140)
Turn the lens hood in the direction of the arrow to detach it
Align the mark ( ) ( ) on the lens hood with the mark on the tip of the lens
Turn the lens hood in the direction of the arrow until it clicks into place

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
