121
VQT1Z56
Connecting to other equipment
Preparations:
Turn on the camera and the PC.
Remove the card before using the pictures in the built-in memory.
A USB connection cable (supplied)
Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which will cause trouble.)
B Align the marks, and insert.
Use a battery with sufficient battery power or the AC adaptor (DMW-AC5E; optional). When
using the AC adaptor (DMW-AC5E; optional), use the multi conversion adaptor (DMW-MCA1;
optional). If the remaining battery power becomes low while the camera and the PC are
communicating, the status indicator blinks and the alarm beeps.
Refer to
Disconnecting the USB connection cable safely (P122) before disconnecting the
USB connection cable. Otherwise, data may be destroyed.
Connect the camera to a PC via the USB connection cable A
(supplied).
Do not use any other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause malfunction.
Acquiring of still pictures and [MOTION JPEG] motion pictures
(other than [AVCHD Lite] motion pictures)
Press 3/4 to select [PC], and then press
[MENU/SET].
If [USB MODE] (P31) is set to [PC] in the [SETUP] menu in
advance, the camera will be automatically connected to the PC
without displaying the [USB MODE] selection screen. Since there
is no need to set this each time you connect to the PC, it is
convenient.
When the camera has been connected to the PC with
[USB MODE] set to [PictBridge(PTP)], a message may appear
on the PC’s screen. Select [Cancel] to close the screen, and
disconnect the camera from the PC. Then set [USB MODE] to
[PC] again.
USB MODE
PLEASE SELECT
THE USB MODE
PictBridge(PTP)
PC
SELECT
SET
DMC-FT1&TS1EB-VQT1Z56_eng.book 121 ペー 009年2月2日 月曜日 午前9時47分

Table of Contents

Other manuals for Panasonic LUMIX DMC-FT1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-FT1 and is the answer not in the manual?

Panasonic LUMIX DMC-FT1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeCCD
Supported aspect ratios3:2, 4:3, 16:9
Digital zoom36 x
Optical zoom4.6 x
Fixed focal length35 mm
Focal length range4.9 - 22.8 mm
Number of aspheric elements5
Interfacemini HDMI
Digital SLRNo
Built-in flashYes
Dimensions (WxDxH)98.3 x 23 x 61.3 mm
Camera shutter speed8 - 1/1300 s
Effective sensor resolution12.7 pixels
Focal length (35mm film equivalent)28 - 128 mm
Normal focusing range0.3 - ∞ m
Macro focusing range (tele)0.3 m
Macro focusing range (wide)0.05 m
Internal memory40 MB
Compatible memory cardsmmc, sd
Maximum video resolution320 x 240 pixels
Display diagonal2.7 \
USB version2.0
Product colorGold
Flash modesauto, fill-in, manual, Red-eye reduction
Light exposure modesauto, manual
Camera shutter typeelectronic, mechanical
Weight and Dimensions IconWeight and Dimensions
Depth23 mm
Width98.3 mm
Height61.3 mm
Weight183.8 g
