Panasonic LUMIX DMC-FT1 - Names of the Components

VQT1Z56
14
Before Use
Names of the Components
1 Flash (P50)
2 Self-timer indicator (P55)
AF assist lamp (P93)/LED light (P75)
3 Lens (P4, 131)
4 LCD monitor (P48, 128)
5 Status indicator (P20, 30, 34)
6 Playback button (P25)
7 [MENU/SET] button (P23)
8 [DISPLAY] button (P48)
9 [Q.MENU] (P27)/Delete (P46) button
10 Motion picture button (P34)
11 Mode dial (P34)
12 Cursor buttons
A: 3/Exposure compensation (P56)/
Auto bracket (P57)/White balance
fine adjustment (P86)
B: 4/Macro mode (P53)
AF Tracking (P39, 88)
C: 2/Self-timer button (P55)
D: 1/Flash setting button (P50)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
21 3
4512
6897
10
11
