15
VQT1Z56
Before Use
13 Shutter button (P37)
14 Camera ON/OFF button (P23)
15 Zoom lever (P43)
16 Microphone (P70, 93, 112)
17 Speaker (P101)
18 Hand strap eyelet (P16)
19 [HDMI] socket (P115, 116)
20 [AV/DIGITAL/MULTI] socket
(P21, 114, 120, 124)
•
When using an AC adaptor, ensure that
the Panasonic multi conversion adaptor
(DMW-MCA1; optional) and AC adaptor
(DMW-AC5E; optional) are used. For
connection details, refer to P21.
21 Tripod receptacle
•
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
22 Card/Battery door (P20)
23 Release lever (P11, 20)
