Panasonic LUMIX DMC-FT1 User Manual

VQT1Z56
124
Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to
be printed out and instruct that printing be started on the camera’s LCD monitor.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures in the built-in memory.
Perform the print quality and other settings at the printer before printing the pictures.
Set the mode dial to anything except [¨].
A USB connection cable (supplied)
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which will cause trouble.)
B Align the marks, and insert.
• Use a battery with sufficient battery power or the AC adaptor (DMW-AC5E; optional). When
using the AC adaptor (DMW-AC5E; optional), use the multi conversion adaptor (DMW-MCA1;
optional). If the remaining battery power becomes low while the camera and the printer are
connected, the status indicator blinks and the alarm beeps. If this happens during printing, stop
printing at once. If not printing, disconnect the USB connection cable.
Connect the camera to a printer via the USB connection cable A
(supplied).
• When the camera is connected to the printer, the cable disconnect prohibit icon [å]
appears. Do not disconnect the USB cable while [å] is displayed.
Press 3/4 to select [PictBridge(PTP)], and then
press [MENU/SET].
USB MODE
SELECT
SET
PLEASE SELECT
THE USB MODE
PictBridge(PTP)
PC
DMC-FT1&TS1EB-VQT1Z56_eng.book 124 ページ ２００９年２月２日 月曜日 午前９時４７分

Panasonic LUMIX DMC-FT1 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Supported aspect ratios	3:2, 4:3, 16:9
Digital zoom	36 x
Optical zoom	4.6 x
Fixed focal length	35 mm
Focal length range	4.9 - 22.8 mm
Number of aspheric elements	5
Interface	mini HDMI
Digital SLR	No
Built-in flash	Yes
Dimensions (WxDxH)	98.3 x 23 x 61.3 mm
Camera shutter speed	8 - 1/1300 s
Effective sensor resolution	12.7 pixels
Focal length (35mm film equivalent)	28 - 128 mm
Normal focusing range	0.3 - ∞ m
Macro focusing range (tele)	0.3 m
Macro focusing range (wide)	0.05 m
Internal memory	40 MB
Compatible memory cards	mmc, sd
Maximum video resolution	320 x 240 pixels
Display diagonal	2.7 \
USB version	2.0
Product color	Gold
Flash modes	auto, fill-in, manual, Red-eye reduction
Light exposure modes	auto, manual
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	23 mm
Width	98.3 mm
Height	61.3 mm
Weight	183.8 g
