Panasonic LUMIX DMC-FT1 User Manual

21
VQT1Z56
Preparation
∫ About the card/battery door.
If you turn on the power with the card/battery door open, a warning sound will go off in order
to avoid immersion and the message shown below will appear on the LCD monitor. (P136)
The camera cannot be operated when the card/battery door is open. (Only the ON/OFF
button can be operated) Close it securely so no foreign object is clamped.
•
Messages are not displayed when the terminal cover is opened. Also, the camera can be
operated, but close the cover securely so no foreign object is clamped before using the
camera.
If there is any foreign object, remove it with attached brush.
∫ Connecting the AC adaptor and multi conversion adaptor instead of the battery
Always purchase the AC adaptor (DMW-AC5E; optional) and the multi conversion adaptor
(DMW-MCA1; optional) as a set. The AC adaptor (DMW-AC5E; optional) cannot be used
by itself. Also, read the instruction for the multi conversion adaptor (DMW-MCA1; optional)
regarding the connection.
1 Open the terminal cover
2 Connect the camera with the multi conversion adaptor (DMW-MCA1; optional)
•
Ensure that only the AC adaptor (DMW-AC5E; optional) and multi conversion adaptor
(DMW-MCA1; optional)
for this camera are used. Using any other equipment may cause
damage.
3 Connect the AC mains lead to the AC adaptor and a wall outlet.
4 Connect the AC adaptor to the multi conversion adaptor.
Note
•
Always use a genuine Panasonic AC adaptor (DMW-AC5E; optional).
• Always use a genuine Panasonic multi conversion adaptor (DMW-MCA1; optional).
BATTERY COVER OPEN
CHECK THAT NO SAND,
HAIR, OR OTHER OBJECTS
ARE ON THE DOOR SEAL.
VQT1Z56~Body1_mst.fm 21 ページ ２００９年２月２日 月曜日 午前１１時４７分

Panasonic LUMIX DMC-FT1 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Supported aspect ratios	3:2, 4:3, 16:9
Digital zoom	36 x
Optical zoom	4.6 x
Fixed focal length	35 mm
Focal length range	4.9 - 22.8 mm
Number of aspheric elements	5
Interface	mini HDMI
Digital SLR	No
Built-in flash	Yes
Dimensions (WxDxH)	98.3 x 23 x 61.3 mm
Camera shutter speed	8 - 1/1300 s
Effective sensor resolution	12.7 pixels
Focal length (35mm film equivalent)	28 - 128 mm
Normal focusing range	0.3 - ∞ m
Macro focusing range (tele)	0.3 m
Macro focusing range (wide)	0.05 m
Internal memory	40 MB
Compatible memory cards	mmc, sd
Maximum video resolution	320 x 240 pixels
Display diagonal	2.7 \
USB version	2.0
Product color	Gold
Flash modes	auto, fill-in, manual, Red-eye reduction
Light exposure modes	auto, manual
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	23 mm
Width	98.3 mm
Height	61.3 mm
Weight	183.8 g
