Panasonic LUMIX DMC-FT1 User Manual

31
VQT1Z56
Preparation
• The folder number is updated and the file number starts from 0001. (P123)
• A folder number between 100 and 999 can be assigned.
When the folder number reaches 999, the number cannot be reset. We recommend formatting
the card (P33) after saving the data on a PC or elsewhere.
• To reset the folder number to 100, format the built-in memory or the card first and then use this
function to reset the file number.
A reset screen for the folder number will then appear. Select [YES] to reset the folder number.
• When the [RESET] setting is selected during recording, the operation that resets the lens is
also performed at the same time. You will hear the sound of the lens operating but this is
normal and not indicative of malfunctioning.
• When the [REC] mode settings are reset, data registered with [FACE RECOG.] will be also
reset, too.
• When [SETUP] menu settings are reset, the following settings are also reset. In addition,
[ROTATE DISP.] (P108) is set to [ON], and [FAVORITE] (P109) is set to [OFF] in [PLAYBACK]
mode menu.
– The birthday and name settings for [BABY1]/[BABY2] (P63) and [PET] (P64) in scene mode.
– The settings of [TRAVEL DATE] (P79) (departure date, return date, location)
– The [WORLD TIME] (P81) setting.
• The folder number and the clock setting are not changed.
• When [PC] is selected, the camera is connected via the “USB Mass Storage” communication
system.
• When [PictBridge(PTP)] is selected, the camera is connected via the “PTP (Picture Transfer
Protocol)” communication system.
• This will operate when the AV cable or HDMI mini cable (optional) is connected.
• This will work when the AV cable is connected.
v [NO.RESET]
Reset the file number of the next recording to 0001.
w [RESET]
The [REC] or [SETUP] menu settings are reset to the initial
settings.
x [USB MODE]
Select the USB communication system after or before connecting
the camera to your PC or your printer with the USB connection
cable (supplied).
y [SELECT ON CONNECTION]:
Select either [PC] or [PictBridge(PTP)] if you connected the
camera to a PC or a printer supporting PictBridge.
{ [PictBridge(PTP)]:
Set after or before connecting to a printer supporting PictBridge.
z [PC]:
Set after or before connecting to a PC.
| [VIDEO OUT]
Set to match the colour television system in each country.
(Playback mode only)
[NTSC]: Video output is set to NTSC system.
[PAL]: Video output is set to PAL system.
[TV ASPECT]
Set to match the type of TV.
(Playback mode only)
[W]: When connecting to a 16:9 screen TV.
[X]: When connecting to a 4:3 screen TV.
DMC-FT1&TS1EB-VQT1Z56_eng.book 31 ページ ２００９年２月２日 月曜日 午前９時４７分

Panasonic LUMIX DMC-FT1 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Supported aspect ratios	3:2, 4:3, 16:9
Digital zoom	36 x
Optical zoom	4.6 x
Fixed focal length	35 mm
Focal length range	4.9 - 22.8 mm
Number of aspheric elements	5
Interface	mini HDMI
Digital SLR	No
Built-in flash	Yes
Dimensions (WxDxH)	98.3 x 23 x 61.3 mm
Camera shutter speed	8 - 1/1300 s
Effective sensor resolution	12.7 pixels
Focal length (35mm film equivalent)	28 - 128 mm
Normal focusing range	0.3 - ∞ m
Macro focusing range (tele)	0.3 m
Macro focusing range (wide)	0.05 m
Internal memory	40 MB
Compatible memory cards	mmc, sd
Maximum video resolution	320 x 240 pixels
Display diagonal	2.7 \
USB version	2.0
Product color	Gold
Flash modes	auto, fill-in, manual, Red-eye reduction
Light exposure modes	auto, manual
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	23 mm
Width	98.3 mm
Height	61.3 mm
Weight	183.8 g
