Preparations
Inserting and Removing the Card (optional)/
the Battery
VQT5B76- 21 -
• Turn this unit off and confirm that the lens barrel is retracted.
• We recommend using a Panasonic card.
Slide the release lever to the
[OPEN] position and open the
card/battery door
Battery:
Being careful about the battery
orientation, insert all the way
and then check that it is locked
by lever.
• Pull the lever in the direction of the
arrow to remove the battery.
Card:
Push it securely all the way
until you hear a “click” while
being careful about the
direction in which you insert it.
• To remove the card, push the card until
it clicks, then pull the card out upright.
Do not touch
the terminals
on the back of
the card.
Lever
Close the card/battery door
and slide the release lever to
the [LOCK] position
To Next Page
