Application (Record)
Useful features for travel
VQT5A33- 126 -
[Travel Date]
If you set your travel schedule and record pictures, the day of your trip on which the
picture was taken will be recorded.
Select [Travel Date] from the [Setup] menu (→52)
Use cursor button to select [Travel Setup] and press
[MENU/SET]
Use cursor button to select [SET] and press [MENU/SET]
Use cursor button to select the departure date and press
[MENU/SET]
Use cursor button to select the return date and press
[MENU/SET]
To record [Location]
Once the [Travel Setup] is set, you can set the location.
Select [Location] in step above
Use cursor button to select [SET] and press [MENU/SET]
Enter your location (Entering text (→65))
The travel date is calculated from the set departure date and the date set in the
camera’s clock. When destination is set in [World Time], days elapsed are calculated
based on local destination time.
When [Travel Setup] is set to [OFF], the number of days elapsed is not recorded. It is
not displayed even if [Travel Setup] is set to [SET] after recording.
If settings are made before departure date, number of days to departure are not
recorded.
To print [Location] or the number of days that have passed, either use [Text Stamp] or
print using the “PHOTOfunSTUDIO” software on the supplied CD-ROM.
[Travel Date] cannot be recorded for AVCHD motion pictures.
[Location] cannot be recorded for MP4 motion pictures.
Cannot be set when using [Intelligent Auto] Mode. The settings in other Recording
Mode are applied.

Table of Contents

Other manuals for Panasonic LUMIX DMC-LF1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-LF1 and is the answer not in the manual?

Panasonic LUMIX DMC-LF1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Image sensor size1/1.7 \
Image formats supportedJPEG XR, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationLens
Still image resolution(s)-
Digital zoom4 x
Optical zoom7.1 x
Extra/Smart zoom14.3 x
Focal length range6 - 42.8 mm
Maximum aperture number5.9
Minimum aperture number2
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto focusing (AF) modesSpot Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAuto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed250 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Audio systemstereo
Memory slots1
Internal memory87 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size64 GB
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)920000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.2 \
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Food, Night, Night landscape, Night portrait, Pet, Sports, Sunset, Landscape (scenery)
Image editingResizing
Photo effectsAntique, Black&White, Sepia, Skin tones
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Scene, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Battery life (CIPA standard)250 shots
Product colorBlack
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2AE, SILKYPIX® Developer Studio, Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth27.9 mm
Width102.5 mm
Height62.1 mm
Weight170 g
Weight (including battery)192 g
