Application (Record)
Taking pictures by setting the aperture value
[Aperture-Priority] Mode
VQT5A33
- 92 -
Recording mode:
When recording, you can control the aperture value to meet your recording purposes.
Shutter speed is automatically adjusted to be appropriate for the set aperture value.
Set mode dial to
Turn the control ring to select the aperture value
You can also make adjustments with the control dial.
When the aperture value is increased, the range of depth in focus expands, and
the picture shows up clearly from the position of the camera to the background.
When the aperture value is reduced, the range of depth in focus shrinks, and the
background can get blurry.
Aperture values that can be set
*
Shutter speed set (seconds)
F2.0 - F8.0 8 - 1/4000
*
You may not be able to select some values depending on zoom position.
About the exposure meter
Shutter speed (Automatic adjustment)
Set aperture value
Proper exposure is not possible in the range indicated in red.
Recording motion pictures in
Aperture and shutter speed are automatically set.
When the picture is too bright or too dark or there is incorrect exposure, the numbers
for the aperture value and shutter speed are shown in red.
LCD monitor or viewfinder brightness may vary from the actual still picture recorded.

Table of Contents

Other manuals for Panasonic LUMIX DMC-LF1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-LF1 and is the answer not in the manual?

Panasonic LUMIX DMC-LF1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Image sensor size1/1.7 \
Image formats supportedJPEG XR, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationLens
Still image resolution(s)-
Digital zoom4 x
Optical zoom7.1 x
Extra/Smart zoom14.3 x
Focal length range6 - 42.8 mm
Maximum aperture number5.9
Minimum aperture number2
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto focusing (AF) modesSpot Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAuto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed250 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Audio systemstereo
Memory slots1
Internal memory87 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size64 GB
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)920000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.2 \
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Food, Night, Night landscape, Night portrait, Pet, Sports, Sunset, Landscape (scenery)
Image editingResizing
Photo effectsAntique, Black&White, Sepia, Skin tones
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Scene, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Battery life (CIPA standard)250 shots
Product colorBlack
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2AE, SILKYPIX® Developer Studio, Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth27.9 mm
Width102.5 mm
Height62.1 mm
Weight170 g
Weight (including battery)192 g
