Page #269 background imageLoading...
Page #269 background image
Others
Q&A Troubleshooting
VQT5A33
- 269 -
Recording
Cannot record pictures.
Built-in memory/card is full.
Free space by deleting unwanted pictures (→50).
Recorded pictures look white.
Lens is dirty (fingerprints, etc.).
Turn the camera on to extract lens barrel, and clean lens surface with a soft, dry cloth.
Lens is foggy (→7).
Recorded pictures are too bright/too dark.
Adjust the exposure (→90).
[Min. Shtr Speed] is set to fast speed. Check the setting (→135).
Some pictures are taken when I press the shutter button just once.
Camera is set to use [Auto Bracket] or [Burst].
Focus not aligned correctly.
Not set to mode appropriate for distance to subject. (Focus range varies according to recording
mode.)
Subject outside of focus range. (→79)
Caused by jitter or subject movement. (→38)
Recorded pictures are blurred. The stabilizer function ineffective.
Shutter speed is slower in dark locations and the stabilizer function is less effective.
Hold camera firmly with both hands, keeping arms close to body.
Use a tripod and the self-timer (→89) when using slower shutter speed with [Min. Shtr Speed].
Cannot use [Auto Bracket].
Only enough memory for 2 pictures or fewer.
Recorded pictures appear coarse, or there is interference.
ISO Sensitivity is high, or shutter speed is low.
(Default [Sensitivity] setting is [AUTO] – interference may appear with indoor pictures.)
Lower [Sensitivity] (→130).
Take pictures in brighter locations.
Striping or flicker may appear under lighting such as fluorescent lighting
and LED lighting fixture.
This is characteristic of MOS sensors which serve as the camera’s pickup sensors.
This is not a malfunction.
Brightness or coloring of recorded picture different from real life.
When recording under fluorescent or LED lighting fixture etc., increasing the shutter speed may
introduce slight changes to brightness and color. These are a result of the characteristics of the light
source and do not indicate a malfunction.
When recording subjects in extremely bright locations or recording under fluorescent lighting, LED
lighting fixture, mercury lamp, sodium lighting etc., the colors and screen brightness may change or
horizontal striping may appear on the screen.

Table of Contents

Other manuals for Panasonic LUMIX DMC-LF1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-LF1 and is the answer not in the manual?

Panasonic LUMIX DMC-LF1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Image sensor size1/1.7 \
Image formats supportedJPEG XR, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationLens
Still image resolution(s)-
Digital zoom4 x
Optical zoom7.1 x
Extra/Smart zoom14.3 x
Focal length range6 - 42.8 mm
Maximum aperture number5.9
Minimum aperture number2
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto focusing (AF) modesSpot Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAuto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed250 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Audio systemstereo
Memory slots1
Internal memory87 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size64 GB
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)920000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.2 \
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Food, Night, Night landscape, Night portrait, Pet, Sports, Sunset, Landscape (scenery)
Image editingResizing
Photo effectsAntique, Black&White, Sepia, Skin tones
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Scene, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Battery life (CIPA standard)250 shots
Product colorBlack
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2AE, SILKYPIX® Developer Studio, Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth27.9 mm
Width102.5 mm
Height62.1 mm
Weight170 g
Weight (including battery)192 g
