VQT1T27
10
Before Use
Names of the Components
1 Lens (P5, 127)
2 Self-timer indicator (P50)
AF assist lamp (P88)
3Flash (P46)
4 Strap eyelet (P13)
•
Be sure to attach the strap when using
the camera to ensure that you will not
drop it.
5 Focus selector switch (P49, 58)
6 LCD monitor (P44, 124)
7 Joystick (P23, 34, 55, 56, 58)
8 [REC]/[PLAYBACK] selector switch (P21)
9 [AF/AE LOCK] button (P84)
10 Status indicator (P18, 26, 32)
11 [MENU/SET] button (P19)
The joystick is operated in two different ways: it can be moved in the up, down, left
and right directions to perform an operation, or it can be pressed to select. In these
operating instructions, it is pictured as shown in the figure below or described with
3/4/2/1.
Example: When the joystick is moved
toward 2 (left)
Place your finger on the right side of the
joystick, and move the joystick toward
the left.
or Move 2
Push the joystick straight in.
or Press
