Panasonic Lumix DMC-LX3 User Manual

15
VQT1T27
Preparation
Preparation
Charging the Battery
• Use the dedicated charger and battery.
• The battery is not charged when the camera is shipped. Charge the battery before use.
• Charge the battery with the charger indoors.
• Charge the battery in a temperature between 10 oC to 35 oC (50 oF to 95 oF). (The battery
temperature should also be the same.)
∫ When the [CHARGE] indicator flashes
•
The battery temperature is excessively high or low. The charging time will be longer than
normal. Also, charging may not be completed.
• The terminals of the charger or the battery are dirty. In this case, wipe them with a dry cloth.
Note
•
After charging is completed, be sure to disconnect the power supply device from the electrical
outlet.
• The battery becomes warm after using it and during and after charging. The camera also
becomes warm during use. This is not a malfunction.
• The battery will be exhausted if left for a long period of time after being charged.
• The battery can be recharged even when it still has some charge left, but it is not
recommended that the battery charge be frequently topped up while the battery is fully
charged. (The battery has characteristics that will reduce its operating duration and cause the
battery to swell up.)
• When the operating time of the camera becomes extremely short even after properly charging
the battery, the life of the battery may have expired. Buy a new battery.
Attach the battery with
attention to the direction of the
battery.
Connect the charger to the
electrical outlet.
• Charging starts when the [CHARGE]
indicator A lights green.
Detach the battery after
charging is completed.
• Charging is complete when the
[CHARGE] indicator A turns off (after
approx. 130 min maximum).
1
2
3
P.PC_DMC-LX3_eng.book 15 ページ ２００８年７月８日 火曜日 午後１０時１３分

Panasonic Lumix DMC-LX3 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2560 x 1920, 3072 x 2304, 3328 x 1872, 3968 x 2232
Digital zoom	4 x
Optical zoom	2.5 x
Combined zoom	10 x
Extra/Smart zoom	4.5 x
Focal length range	5.1 - 12.8 mm
Number of aspheric elements	4
Lens structure (elements/groups)	8/6
Digital SLR	No
Aperture range (F-F)	2 - 8
Camera shutter speed	1/60 - 1/2000 s
Focal length (35mm film equivalent)	24 - 60 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 5.9 m
Flash range (wide)	0.8 - 8.3 m
Scene modes	Beach, Candlelight, Children, Fireworks, Night landscape, Portrait, Snow, Sports, Sunset
Image editing	Rotating, Trimming
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Shade
Shooting modes	Aperture priority, Auto, Movie, Shutter priority
Camera playback	Movie, Single image, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Internal memory	50 MB
Compatible memory cards	SD, SDHC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.7 V
Battery capacity	1150 mAh
Battery life (CIPA standard)	380 shots
Cables included	AV, USB

Weight and Dimensions

Depth	27.1 mm
Width	108.7 mm
Height	59.5 mm
Weight	265 g
Weight (including battery)	290 g
