Panasonic Lumix DMC-LX3 User Manual

VQT1T27
130
Others
Functions that cannot be set or will not work
under some conditions
Due to the camera’s specifications, it may not be possible to set some of the functions or
some functions may not work in some of the conditions under which the camera is used.
The table below lists these functions and the corresponding conditions.
[MEMORY CARD ERROR
PLEASE CHECK THE CARD]
•
An error has occurred accessing the card.
> Insert the card again.
• Or try with a different card.
[READ ERROR
PLEASE CHECK THE CARD]
•
An error has occurred reading the data.
> Insert the card again.
[WRITE ERROR
PLEASE CHECK THE CARD]
•
An error has occurred writing the data.
> Turn the camera off and remove the card. Insert the card again and turn the camera on.
Make sure the camera is turned off before removing or inserting the card to avoid
damage.
• Or try with a different card.
[MOTION RECORDING WAS CANCELLED DUE TO THE LIMITATION OF THE
WRITING SPEED OF THE CARD]
•
When you set the picture quality to [ ], [ ] or [ ], we recommend using a high-speed
card with “10MB/s” or greater displayed on the package.
• Depending on the type of SD Memory Card or SDHC Memory Card, motion picture recording
may stop in the middle.
[A FOLDER CANNOT BE CREATED]
•
A folder cannot be created because there are no remaining folder numbers that can be used.
(P112)
> Format the card after saving necessary data on a PC etc. (P28) If you execute
[NO.RESET] in the [SETUP] menu after formatting, the folder number is reset to 100.
(P26)
[PICTURE IS DISPLAYED FOR 4:3 TV]/[PICTURE IS DISPLAYED FOR 16:9 TV]
•
The AV cable is connected to the camera.
> Press [MENU/SET] if you want to delete this message at once.
> Select [TV ASPECT] in the [SETUP] menu if you want to change the TV aspect. (P27)
• This message also appears when the USB connection cable is connected to the camera only.
In this case, connect the other end of the USB connection cable to a PC or a printer. (P110,
112)
[PRINTER BUSY]/[PLEASE CHECK THE PRINTER]
•
The printer cannot print.
> Check the printer.
P.PC_DMC-LX3_eng.book 130 ページ ２００８年７月８日 火曜日 午後１０時１３分

Panasonic Lumix DMC-LX3 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2560 x 1920, 3072 x 2304, 3328 x 1872, 3968 x 2232
Digital zoom	4 x
Optical zoom	2.5 x
Combined zoom	10 x
Extra/Smart zoom	4.5 x
Focal length range	5.1 - 12.8 mm
Number of aspheric elements	4
Lens structure (elements/groups)	8/6
Digital SLR	No
Aperture range (F-F)	2 - 8
Camera shutter speed	1/60 - 1/2000 s
Focal length (35mm film equivalent)	24 - 60 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 5.9 m
Flash range (wide)	0.8 - 8.3 m
Scene modes	Beach, Candlelight, Children, Fireworks, Night landscape, Portrait, Snow, Sports, Sunset
Image editing	Rotating, Trimming
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Shade
Shooting modes	Aperture priority, Auto, Movie, Shutter priority
Camera playback	Movie, Single image, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Internal memory	50 MB
Compatible memory cards	SD, SDHC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.7 V
Battery capacity	1150 mAh
Battery life (CIPA standard)	380 shots
Cables included	AV, USB

Weight and Dimensions

Depth	27.1 mm
Width	108.7 mm
Height	59.5 mm
Weight	265 g
Weight (including battery)	290 g
