Panasonic Lumix DMC-LX3 User Manual

37
VQT1T27
Basic
It is possible to set the focus to the specified subject. Focus will keep following the subject
automatically even if it moves. Refer to P83 for details.
•
Set the [AF TRACKING] in the [REC] mode menu to [ON]. ([ ] is displayed on the screen.)
Bring the subject to the AF tracking frame, and press
[AF/AE LOCK] to lock the subject.
•
AF tracking frame will turn yellow.
• An optimum scene for the specified subject will be chosen.
• Press [AF/AE LOCK] again to cancel.
• Open the flash when the flash is to be used. (P46)
• When [‡] is selected, [ ], [ ] or [ ] is set depending on the type of subject and
brightness.
• When [ ] or [ ] is set, digital red-eye correction (P47) will turn on and flash is
activated twice.
• Flash modes cannot be switched using 1 (‰) in the intelligent auto mode.
• Only the following functions can be set in this mode.
[REC] mode menu
– [PICTURE SIZE]
¢
(P76)/[AF TRACKING] (P83)
¢ The settings which can be selected are different from when other [REC] modes are used.
[SETUP] menu
– [CLOCK SET]/[WORLD TIME]/[TRAVEL DATE]/[BEEP]/[LANGUAGE]
• The settings of the following items are fixed.
AF Tracking Function
About the flash
Settings in Intelligent auto mode
Item Settings
[Fn BUTTON SET] (P24) o
[GUIDE LINE] (P25) ([REC. INFO.]: [OFF])
[ECONOMY]
([POWER SAVE]) (P26)
[5MIN.]
[AUTO REVIEW] (P26) [2SEC.]
Focus range The focus range becomes the same as AF macro mode.
[1 cm (0.04 feet) (Wide)/30 cm (0.99 feet) (Tele) to ¶ ] (P49)
• The maximum close-up distance (the shortest distance at
which the subject can be taken) differs depending on the
zoom magnification.
Self-timer (P50) 10 seconds
[FILM MODE] (P74) [STANDARD]
[QUALITY] (P77) A (Set to [›] when picture size is [ ] (0.3M ))
[INTELLIGENT ISO] (P78) [ON] (The maximum ISO sensitivity: ISO800)
[ISO LIMIT SET] (P79) 800
[WHITE BALANCE] (P79) [AWB]
AF/AE
LOCK
P.PC_DMC-LX3_eng.book 37 ページ ２００８年７月８日 火曜日 午後１０時１３分

Panasonic Lumix DMC-LX3 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2560 x 1920, 3072 x 2304, 3328 x 1872, 3968 x 2232
Digital zoom	4 x
Optical zoom	2.5 x
Combined zoom	10 x
Extra/Smart zoom	4.5 x
Focal length range	5.1 - 12.8 mm
Number of aspheric elements	4
Lens structure (elements/groups)	8/6
Digital SLR	No
Aperture range (F-F)	2 - 8
Camera shutter speed	1/60 - 1/2000 s
Focal length (35mm film equivalent)	24 - 60 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 5.9 m
Flash range (wide)	0.8 - 8.3 m
Scene modes	Beach, Candlelight, Children, Fireworks, Night landscape, Portrait, Snow, Sports, Sunset
Image editing	Rotating, Trimming
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Shade
Shooting modes	Aperture priority, Auto, Movie, Shutter priority
Camera playback	Movie, Single image, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Internal memory	50 MB
Compatible memory cards	SD, SDHC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.7 V
Battery capacity	1150 mAh
Battery life (CIPA standard)	380 shots
Cables included	AV, USB

Weight and Dimensions

Depth	27.1 mm
Width	108.7 mm
Height	59.5 mm
Weight	265 g
Weight (including battery)	290 g
