Connecting to other equipment
• When pictures are displayed, they may not be displayed properly depending on the type of TV.
• Read the operating instructions for the TV.
Using the Conversion Lens (optional)
When the wide conversion lens is used, it is possible to achieve a wider field of view in
pictures of landscapes or the like.
Refer to P90 for details.
Preparations: Turn off the camera and remove the lens cap.
Remove the lens ring front.
• Be careful not to lose the lens ring front.
Attach the lens adaptor.
A Lens adaptor (DMW-LA4; optional)
• The conversion lens and filters cannot be used
together. If any of these are fitted, be sure to remove
before fitting the conversion lens.
• Rotate the lens slowly and carefully.
Attach the wide conversion lens.
B Wide conversion lens (DMW-LW46; optional)
• Ensure that screw parts of the lens adaptor and
wide conversion lens are properly tightened.
∫ The Focus Range When Using the Wide
Conversion Lens
•
The focus range is 0.75 times the focal distance of the camera.
Wide Conversion Lens
Indication 1
k
Actual magnification 0.75k
35 mm film camera equivalent 18 mm
