Panasonic Lumix DMC-LX3 User Manual

111
VQT1T27
Connecting to other equipment
Using a drag-and-drop operation, move the pictures you want to
acquire or the folder storing those pictures to any different folder on
the PC.
∫ Disconnecting the USB connection cable safely
•
Proceed with the hardware removal using “Safely Remove Hardware” on the task tray of the
PC. If the icon is not displayed, check that [ACCESS] is not displayed on the LCD monitor of
the digital camera before removing the hardware.
Note
•
Turn the camera off before connecting or disconnecting the AC adaptor (DMW-AC5PP;
optional).
• Before inserting or removing a card, turn the camera off and disconnect the USB connection
cable. Otherwise, data may be destroyed.
• With the Mac OS X v10.2 or an earlier operating system, set the Write-Protect switch of the
SDHC memory card to the [LOCK] position when importing pictures from an SDHC memory
card.
Press 3/4 to select [PC], and then press [MENU/
SET].
• If [USB MODE] (P27) is set to [PC] in the [SETUP] menu in
advance, the camera will be automatically connected to the PC
without displaying the [USB MODE] selection screen. Since there
is no need to set this each time you connect to the PC, it is
convenient.
• When the camera has been connected to the PC with
[USB MODE] set to [PictBridge(PTP)], a message may appear
on the PC’s screen. Select [Cancel] to close the screen, and
disconnect the camera from the PC. Then set [USB MODE] to
[PC] again.
Double-click on [Removable Disk] in [My Computer].
• When using a Macintosh, the drive is displayed on the desktop. (“LUMIX”, “NO_NAME”
or “Untitled” is displayed.)
Double-click [DCIM] folder.
2
USB MODE
SELECT
SET
PLEASE SELECT
THE USB MODE
PictBridge(PTP)
PC
MENU
3
4
5
P.PC_DMC-LX3_eng.book 111 ページ ２００８年７月８日 火曜日 午後１０時１３分

Panasonic Lumix DMC-LX3 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2560 x 1920, 3072 x 2304, 3328 x 1872, 3968 x 2232
Digital zoom	4 x
Optical zoom	2.5 x
Combined zoom	10 x
Extra/Smart zoom	4.5 x
Focal length range	5.1 - 12.8 mm
Number of aspheric elements	4
Lens structure (elements/groups)	8/6
Digital SLR	No
Aperture range (F-F)	2 - 8
Camera shutter speed	1/60 - 1/2000 s
Focal length (35mm film equivalent)	24 - 60 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 5.9 m
Flash range (wide)	0.8 - 8.3 m
Scene modes	Beach, Candlelight, Children, Fireworks, Night landscape, Portrait, Snow, Sports, Sunset
Image editing	Rotating, Trimming
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Shade
Shooting modes	Aperture priority, Auto, Movie, Shutter priority
Camera playback	Movie, Single image, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Internal memory	50 MB
Compatible memory cards	SD, SDHC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.7 V
Battery capacity	1150 mAh
Battery life (CIPA standard)	380 shots
Cables included	AV, USB

Weight and Dimensions

Depth	27.1 mm
Width	108.7 mm
Height	59.5 mm
Weight	265 g
Weight (including battery)	290 g
