Panasonic Lumix DMC-LX3 User Manual

VQT1T27
122
Connecting to other equipment
Press 3/4 to select a mode.
• What screen will be displayed here depends on the flash
mode setting of the external flash unit
Press [MENU/SET].
• While the external flash is connected, the following icons are
displayed.
∫ Number of pictures taken in burst mode when using external flash.
•
You can take up to 3 pictures by keeping the shutter button pressed down.
• Depending on the extra flash you use or the recording conditions, you cannot take pictures in
this mode or the amount of light may become insufficient for the second or subsequent
pictures.
Note
•
When the flash mode of the dedicated flash is set to [TTL AUTO], various different flash
settings can be selected to suit the recording mode. For the flash settings that can be selected,
refer to P46.
• When the flash mode of the dedicated flash is set to [TTL AUTO] or [AUTO], the flash output
can be adjusted by the camera. For details, refer to the operating instructions of the dedicated
flash.
• You can set the aperture value, the shutter speed and the ISO sensitivity on the camera even
when attaching the external flash.
• Some commercial external flashes have synchro terminals with high-voltage or reversed
polarity. Using such extra flashes may cause a malfunction or the camera may not operate
normally.
• If you use commercially available external flashes with communication functions other than the
dedicated one, they may not operate normally or they may be damaged. Do not use them.
• Even if the external flash is turned off, the camera may enter the external flash mode when the
external flash is attached. When you are not using the external flash, detach it or set it to
Forced OFF.
• When attaching the external flash, the built-in flash cannot be activated.
• Do not open the built-in flash when an external flash is attached.
• The camera will become unstable when attaching the external flash, it is recommended to use
a tripod when taking picture.
• Turn off the camera when removing the external flash.
• Detach the external flash when carrying the camera.
• When attaching the external flash, do not hold only the external flash because it may detach
from the camera.
• If you use the external flash when the white balance is set to [ ] finely adjust the white
balance depending on the picture quality. (P80)
• If you take pictures close to the subject in Wide, the vignetting effect may appear on the bottom
of the recorded picture.
• Read the operating instructions of the external flash for details.
/ External flash active
/ External flash Forced OFF
[OFF] [˜] [ò]
Burst speed
(pictures/second)
— 2.5 Approx. 2
Number of recordable
pictures (pictures)
—max. 3
3
4
P.PC_DMC-LX3_eng.book 122 ページ ２００８年７月８日 火曜日 午後１０時１３分

Panasonic Lumix DMC-LX3 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2560 x 1920, 3072 x 2304, 3328 x 1872, 3968 x 2232
Digital zoom	4 x
Optical zoom	2.5 x
Combined zoom	10 x
Extra/Smart zoom	4.5 x
Focal length range	5.1 - 12.8 mm
Number of aspheric elements	4
Lens structure (elements/groups)	8/6
Digital SLR	No
Aperture range (F-F)	2 - 8
Camera shutter speed	1/60 - 1/2000 s
Focal length (35mm film equivalent)	24 - 60 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 5.9 m
Flash range (wide)	0.8 - 8.3 m
Scene modes	Beach, Candlelight, Children, Fireworks, Night landscape, Portrait, Snow, Sports, Sunset
Image editing	Rotating, Trimming
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Shade
Shooting modes	Aperture priority, Auto, Movie, Shutter priority
Camera playback	Movie, Single image, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Internal memory	50 MB
Compatible memory cards	SD, SDHC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.7 V
Battery capacity	1150 mAh
Battery life (CIPA standard)	380 shots
Cables included	AV, USB

Weight and Dimensions

Depth	27.1 mm
Width	108.7 mm
Height	59.5 mm
Weight	265 g
Weight (including battery)	290 g
