Panasonic Lumix DMC-LX3 User Manual

VQT1T27
138
Others
• [ROTATE DISP.] (P104) is set to [ON].
• You can rotate pictures with the [ROTATE] function. (P104)
• Is the [REC]/[PLAYBACK] selector switch set to [(]? (P40)
• Is there a picture on the built-in memory or the card?
> The pictures on the built-in memory appear when a card is not inserted. The picture data on
the card appears when a card is inserted.
• Is this a picture whose file name has been changed in the PC? If it is, it cannot be played back
by this unit.
• Has [CATEGORY PLAY] or [FAVORITE PLAY] been set for playback?
> Change to [NORMAL PLAY]. (P40)
• Is this a non-standard picture, a picture which has been edited using a PC or a picture which
was taken by another make of digital camera?
• Did you remove the battery immediately after picture-taking or did you take the picture using a
battery with a low remaining charge?
> Format the data to delete the pictures mentioned above. (P28)
(Other pictures will be deleted as well and it will not be possible to restore them.
Therefore, check well before formatting.)
•
Is the clock in the camera set properly? (P19)
• When pictures edited using a PC or pictures taken by other equipment are searched, they may
be displayed on dates differing from the actual dates on which the pictures were taken.
• Is it a picture that has been recorded with other equipment? In such cases, these pictures may
be displayed with a deteriorated picture quality.
Playback
The picture being played back is rotated and displayed in an unexpected
direction.
The picture is not played back.
The recorded pictures are not displayed.
The folder number and the file number are displayed as [—] and the screen turns
black.
With a calendar search, pictures are displayed on dates differing from the actual
dates on which the pictures were taken.
White round spots like soap bubbles appear on the recorded picture.
• If you take a picture with the flash in a dark place or indoors, white
round spots may appear on the picture caused by the flash reflecting of
particles of dust in the air. This is not a malfunction.
A characteristic of this is that the number of round spots and their
position differ in every picture.
[THUMBNAIL IS DISPLAYED] appears on the screen.
P.PC_DMC-LX3_eng.book 138 ページ ２００８年７月８日 火曜日 午後１０時１３分

Panasonic Lumix DMC-LX3 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	640 x 480, 1600 x 1200, 1920 x 1080, 2048 x 1360, 2048 x 1536, 2560 x 1920, 3072 x 2304, 3328 x 1872, 3968 x 2232
Digital zoom	4 x
Optical zoom	2.5 x
Combined zoom	10 x
Extra/Smart zoom	4.5 x
Focal length range	5.1 - 12.8 mm
Number of aspheric elements	4
Lens structure (elements/groups)	8/6
Digital SLR	No
Aperture range (F-F)	2 - 8
Camera shutter speed	1/60 - 1/2000 s
Focal length (35mm film equivalent)	24 - 60 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	0.01 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Flash modes	Auto, Flash off, Flash on, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 5.9 m
Flash range (wide)	0.8 - 8.3 m
Scene modes	Beach, Candlelight, Children, Fireworks, Night landscape, Portrait, Snow, Sports, Sunset
Image editing	Rotating, Trimming
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Shade
Shooting modes	Aperture priority, Auto, Movie, Shutter priority
Camera playback	Movie, Single image, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DPOF 1.1, Exif 2.2
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480 pixels
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Analog signal format system	NTSC, PAL
Internal memory	50 MB
Compatible memory cards	SD, SDHC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.7 V
Battery capacity	1150 mAh
Battery life (CIPA standard)	380 shots
Cables included	AV, USB

Weight and Dimensions

Depth	27.1 mm
Width	108.7 mm
Height	59.5 mm
Weight	265 g
Weight (including battery)	290 g
