3) Press as to select [KEYSTONE].
4) Press the <ENTER> button.
f The [KEYSTONE] individual adjustment screen is displayed.
5) Press asqw to adjust the item.
Items Operation Adjustment
[H]
Press the q button.
Left side will be
smaller.
Press the w button.
Right side will be
smaller.
[V]
Press the a button.
Upper will be
smaller.
Press the s button.
Lower will be
smaller.
Note
f Pressing the <ENTER> button while the individual adjustment screen is displayed can switch to the individual adjustment screen of other
items.
f The image quality may degrade and it becomes difcult to focus as the amount of correction increases. When installing the projector, try to
ensure that the amount of correction required is minimal.
Setting [CORNER CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
2) Press the <ENTER> button.
f The [SCREEN ADJUSTMENT] screen is displayed.
3) Press as to select [CORNER CORRECTION].
4) Press the <ENTER> button.
f The [CORNER CORRECTION] screen is displayed.
5) Press as to select the item to adjust. Then press the <ENTER> button.
f The [CORNER CORRECTION] individual adjustment screen is displayed.
6) Press asqw to adjust.
[CORNER CORRECTION]
[UPPER LEFT] [UPPER RIGHT] [LOWER LEFT] [LOWER RIGHT]
Note
f When the [CORNER CORRECTION] individual adjustment screen is displaying, the individual adjustment screen of the next corner can also
be displayed by pressing the <ENTER> button.
f Depending on the correction amount, the image aspect ratio may change.
Setting [CURVED CORRECTION]
1) Press as to select [SCREEN ADJUSTMENT].
70 - ENGLISH
Chapter 4 Settings - [POSITION] menu
