Panasonic PT-VMZ50

[NETWORK] menu
On the menu screen, select [NETWORK] from the main menu, and select an item from the submenu.
Refer to “Navigating through the menu” (x page 59) for the operation of the menu screen.
f To use the wireless LAN function with the projector, it is necessary to attach the optional Wireless Module
(Model No.: AJ-WM50).
[DIGITAL LINK MODE]
(Not available for PT-VMZ40)
Switch the communication method of the <DIGITAL LINK/LAN> terminal of the projector.
1) Press as to select [DIGITAL LINK MODE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[AUTO]
Switches the communication method automatically to DIGITAL LINK, long reach or Ethernet.
[DIGITAL LINK]
Fixes the communication method to DIGITAL LINK.
[LONG REACH]
Fixes the communication method to long reach.
[ETHERNET]
Fixes the communication method to Ethernet.
Possible communication modes
l: Communication possible
―: Communication not possible
Setting
Communication possibility
Image transfer
(100 m (328'1"))
Image transfer
(150 m (492'2"))
Ethernet RS-232C
[AUTO]
For DIGITAL LINK
l
―
l l
For long reach
―
l l l
For Ethernet
― ―
l
*1
―
[DIGITAL LINK]
l
―
l l
[LONG REACH]
―
l l l
[ETHERNET]
― ―
l
*1
―
*1 Communication via a twisted-pair-cable transmitter is not available. Connect the projector to the network directly.
Note
f The maximum transmission distance between the twisted-pair-cable transmitter and the projector is 100 m (328'1") for the signal with
resolution of 1 920 x 1 200 dots or less. For the signal with the resolution exceeding 1 920 x 1 200 dots, the maximum transmission distance
will be 50 m (164'1").
f The maximum transmission distance when connected with the long-reach communication method is 150 m (492'2"). In this case, the signal
that the projector can receive is only up to 1080/60p (1 920 x 1 080 dots, dot clock frequency 148.5 MHz).
f When the communication method of the twist-pair-cable transmitter is set to long reach, the projector will connect with long-reach
communication method when [DIGITAL LINK MODE] is set to [AUTO]. To connect with the optional DIGITAL LINK Switcher (Model No.: ET-
YFB200G) with the long-reach communication method, set [DIGITAL LINK MODE] to [LONG REACH].
f Connection will not be made correctly if the twist-pair-cable transmitter does not support the long-reach communication method even if
[DIGITAL LINK MODE] is set to [LONG REACH].
[DIGITAL LINK STATUS]
(Not available for PT-VMZ40)
Display the DIGITAL LINK connection environment.
1) Press as to select [DIGITAL LINK STATUS].
2) Press the <ENTER> button.
f The [DIGITAL LINK STATUS] screen is displayed.
[LINK STATUS]
The content of display is as follows.
[DIGITAL LINK]: Communicating in the DIGITAL LINK method.
[LONG REACH]: Communicating in the long reach method.
[ETHERNET]: Communicating in the Ethernet method.
[NO LINK]: Communication is not established.
ENGLISH - 95
Chapter 4 Settings - [NETWORK] menu
