Pin No. Mark I/O Function
58 M2_F O Changer Motor 2
Forward Control
59 REC O when record circuit is
operating DURING
RECORDING=H
60 KEY_LED O Dimmer ON=L, Dimmer
Off=H-
61 PHOTO I PHOTO (SG Mechanism
only)
62 VCC - Power Supply (+5V)
63 EE_DAT I/O EE_DAT
64 VSS - Ground (0V)
65 DMT O Deck Mute at mecha
transition L=mute OFF,
H=mute ON
66 BP1 O AM beatproof 1 output L
=BP1, H=BP2
67 ASP_CLK O ASP CLK
68 ASP_DAT O ASP DATA
69 N.C. - No Connection
70 N.C. - No Connection
71 N.C. - No Connection
72 N.C. - No Connection
73 N.C. - No Connection
74 N.C. - No Connection
75 MEM_RST O Flash memory reset
76 MEM_WP O Flash Memory Write
Protect
77 JOG1 I JOG SEARCH 1
78 JOG2 I JOG SEARCH 2
79 /CD O CD POWER CONTROL
(Active Low)
80 CD_RST O CD Reset Output
81 N.C. - No Connection
82 /RESTSW I CD Limit Switch Input
for the Most Inner Point
(Active Low)
83 N.C. - No Connection
84 N.C. - No Connection
85 SSEQ_LED O Super Sound EQ LED
Control
86 RE_LED O MP3/WMA Re-master
Control
