Pin No. Mark I/O Function
28 FL_CLK O Serial Clock to FL Driver
29 /FL_RESET O Reset Input (ACTIVEL)
30 FL_DOUT O Sarial Data To FL Driver
(Output)
31 RXD - No Connection
32 TXD - No Connection
33 SCLK - No Connection
34 BUSY - No Connection
35 MEM_SI O Flash Memory Serial
Input
36 MEM_SO I Flash Memory Serial
Output
37 MEM_CK O Flash Memory Serial
Clock
38 MEM_CS O Flash Memory Chip
Select
39 MCLK O CD Command CLK
Output
40 MUTE_A O Audio Mute
41 EPM - -
42 MDATA O CD Command Data
Output
43 MLD O CD Command Load
Output/
44 RDS_CLK I RDS Clock Input
45 RDS_DAT I RDS Data Input
46 CE O -
47 DCDET I DC Detect Input
48 STATUS I CD Servo LSI Status
Input (Inverted)
49 PCONT O Main Transformer
Control Output
50 PLAY_SW I Play Switch (CR16)
51 ST_SW I Stock Switch (CR16)
52 OP_SW I Open Switch (CR16)
53 POS I Position Switch (CR16)
54 BT_SW I Bottom Switch (CR16)
55 M1_R O Changer Motor 1
Reverse Control
56 M1_F O Changer Motor 1
Forward Control
57 M2_R O Changer Motor 2
Reverse Control
