27
IN4
I
Motor
Driver
(
4)
Input
Pin
No.
Mark I/O Function
27 IN3 I Motor Driver (3) Input
20.4. IC302 (C2CBJF000016) MICRO PROCESSOR
Pin No. Mark I/O Function
1 CH_SW I Change Switch (CR16)
2 TU_TUNED I Tuner tuned signal
3 TU_ST I Tuner Stereo signal
4
TU_CK I Tuner Serial Clock Input
5
TU_SDA I Tuner Serial Data Input
6 MBP1
O
Microcomputer Beat
Proof Output 1
(CONTROL)
7 MBP2 O Microcomputer Beat
Proof Output 2
(CONTROL)
8 BYTE - External Data Bus
Width Select Input
(Connect To Ground)
9 CNVSS - Flash Mode Terminal
(Connect To Ground)
10 XCIN - 32.768 kHz Sub Clock
11 XCOUT - 32.768 kHz Sub Clock
12 /RESET - Reset Input (ACTIVEL)
13 XOUT - 10 MHz Main Clock
14 VSS - Ground (0V)
15 XIN - 10 MHz Main Clock
16 VCC - Power Sipply (+5V)
17 /NMI
-
Connect to Vcc (+5V)
18 RMT I Remote Control Input
19 BLKCK I CD Block Clock Input
(Inverted)
20 SYNC I AC Failure Detect Input
21 MUTE_H O HIC Mute
22 EE_CS/ O EEPROM Chip Select
23 EE_CLK O EEPROM CLOCK
24 MUTE_T O H=Tuner muting
25 MUTE_X O A=AUX muting
26 FL_CS1 O FL Driver Chip Select
(Master)
27 FL_CS2 O FL Driver Chip Select
(PM 29 ONLY)
