9.19. Disassembly of Optical Pickup
(CD Mechanism Unit)
·
Follow the (Step 1) - (Step 4) of Item 9.4.
·
Follow the (Step 4) - (Step 6) of Item 9.5.
·
Follow the (Step 1) - (Step 4) of Item 9.8.
·
Follow the (Step 1) - (Step 2) of Item 9.10 .
·
Follow the (Step 1) - (Step 4) of Item 9.12.
·
Follow the (Step 1) - (Step 3) of Item 9.16.
·
Follow the (Step 1) - (Step 4) of Item 9.18.1.
32
SA-PM33EE
