Panasonic SA-PM33EE - 17 Notes of Schematic Diagram

(All schematic diagrams may be modified at any time with
the development of new technology)
Note :
S780 CD Open switch
S900 Stop/-Demo switch
S901 CD switch
S902 Tape switch
S903 Tuner/Band switch
S904 FF/Tune Up switch
S905 REW/Tune Dwn switch
S906 Power switch
S907 CD Open/Close switch
S908 Bass/Treble switch
S909 Rec switch
S910 Music Port switch
S971 Mode switch
S972 Half switch
S973 CR02 switch
S975 Recinh_F switch
S1000 Tape Eject switch
S7201 Reset switch
VR900 VR Volume Jog
· The voltage value and waveforms are the reference voltage
of this unit measured by DC electro nic voltmeter (high
impedance) and oscilloscope on the basis of chassis.
Accordingly, there may arise some error in voltage values
and waveforms depending upon the internal impedance of
the tester or the measuring unit.
· Importance safety notice :
Components identified by
mark have special
characteristics important for safety. Furthermore, special
parts which have purposes of fire-retardant (resistors), high-
quality sound (capacitors), low-noise (resistors), etc. are
used. When replacing any of components, be sure to use
only manufacturer´s specified parts shown in the parts list.
Caution !
IC, LSI and VLSI are sensitive to static electricity.
Secondary trouble can be prevented by taking care during
repair.
· Cover the parts boxes made of plastics with aluminium foil.
· Put a conductive mat on the work table.
· Ground the soldering iron.
· Do not touch the pins of IC, LSI or VLSI with fingers directly.
17 Notes of Schematic Diagram
61
SA-PM33EE
