Notes:
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0112 19P FFC (DECK-MAIN) [M]
2 REEV0113 15P FFC [M]
3 REEV0114 17P FFC (CD-MAIN) [M]
4 REXV0062 WIRE 8P (PWR-TRAN) [M]
5 RFKGAPM33EBS FRONT PANEL ASS’Y [M]
6 RGKV0149-S VOLUME ORNAMENT [M]
7 RGLV0061-Q LIGHTING TIP [M]
8 RKSV0035-H REAR CABINET [M]
9 RGU2280-S CASS EJECT BUTTON [M]
10 RGUV0134C-S FUNCTION BUTTON [M]
11 RGUV0156-S POWER BUTTON [M]
12 RGUV0157-S STOP BUTTON [M]
13 RGUV0158-S CD EJECT BUTTON [M]
14 RGUV0159-S CONTROL BUTTON [M]
15 RGWV0039-S VOLUME KNOB [M]
16 RHD26046-L SCREW [M]
17 RMNV0062 FL HOLDER [M]
18 RHDV30005 SCREW [M]
19 RHDV30007 SCREW [M]
20 RHGV0008 LEG CUSHION [M]
21 RKF0688-S CASS HOLDER/LID [M]
22 RKFV0059-S CD LID [M]
23 RKMV0064-H SIDE PANEL (L) [M]
24 RKMV0065-H SIDE PANEL (R) [M]
25 RKMV0066-S TOP CABINET [M]
26 RMAV0001 MAIN PCB SUPPORT [M]
27 RMB0448-J LOCK ROD SPRING [M]
28 RMBV0046 CASS LID OPEN SPRING [M]
29 RMKV0051 BOTTOM CHASSIS [M]
30 RMM0163-1 CASSETTE LOCK ROD [M]
31 RSCV0073 REAR SHIELD [M]
32 RUS757ZAA CASS HALF SPRING [M]
33 RXGX0002 DAMPER GEAR [M]
34 RXXV0040 HEAT SINK UNIT [M]
35 SHE187-4J POWER PCB SUPPORT [M]
36 RWJ1104150QX 4P WIRE [M]
37 XTB3+10JFJ SCREW [M]
Ref.
No.
Part No. Part Name & Description Remarks
38 XTB3+20JFJK SCREW [M]
39 XTB3+8FFJ SCREW [M]
40 XTV3+10GFJ-M SCREW [M]
41 XTV3+8FFJ SCREW [M]
42 RWJ1105205QX 5P WIRE (PANEL-TRAN) [M]
CASSETTE DECK
101 RED0067-2 R/P HEAD BLOCK UNIT [M]
103 RDG0300 REEL BASE GEAR [M]
104 RDG0301 WINDING RELAY GEAR [M]
105 RDK0026-4 MAIN GEAR [M]
107 RDV0033-4 WINDING BELT [M]
108 RDV0064-1 CAPSTAN BELT [M]
110 RMB0312 TRIGGER LEVER SPRING [M]
111 RMB0400 REEL SPRING [M]
112 RMB0403 HEAB PANEL SPRING [M]
113 RMB0404 BRAKE ROD SPRING [M]
114 RMB0406-5 FR LEVER SPRING [M]
115 RMB0408 THRUST SPRING [M]
116 RML0370-4 TRIGGER LEVER [M]
117 RML0371 FR LEVER [M]
118 RML0372-2 WINDING LEVER [M]
119 RML0374-2 EJECT LEVER [M]
120 RMM0131-1 BRAKE ROD [M]
121 RMM0133-1 EJECT ROD [M]
122 RMQ0519 REEL HUB [M]
123 RMS0398-1 MOVING CORE [M]
124 RXQ0470-2 PLUNGER [M]
125 RMC0061 PACK SPRING [M]
126 RXF0061-1 FLYWHEEL F ASS’Y [M]
128 RXG0040 FF RELAY GEAR ASS’Y [M]
129 RMK0283A-2 SUB-CHASSIS [M]
130 RXL0124 PINCH ROLLER F ASS’Y [M]
130-1 RMB0401 PINCH ARM SPRING F [M]
132 RXL0126 WINDING ARM ASS’Y [M]
133 RXQ0412-3 HEAD PANEL ASS’Y [M]
133-1 RMB0405-1 FR ROD SPRING [M]
133-2 RMM0132-1 FR ROD [M]
24 Replacement Parts List
·
Important safety notice:
Components identified by
mark have special characteristics import ant for safety.
Furthe rmore, special parts which have purposes of fire-retardent (resistors), high-quality sound (capacitors), low noise
(resistors), etc are used.
When replacing any of these components, be sure to use only manufacturer’s specified parts shown in the parts list.
·
The parenthesized indications in the Remarks columns specify the areas or colour. (Refer to the cover page for area or colour)
Parts without these indications can be used for all areas.
·
Warning: This product uses a laser diode. Refer to “Precaution of Laser Diode”.
·
Capacitor values are in microfarads (µF) unless specified otherwise, P= Pico-farads (pF), F= Farads.
·
Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM).
·
The marking (RTL) indicates that the Retention Time is limited for this items. After the discontinuation of this assembly in
production, the item will continue to be available for a specific period of time. The retention period of a availability is dependent
on the type of assembly, and in accordance with the laws governing part and product retention. After the end of this period, the
assembly will no longer be available.
·
[M] Indicates in the Remarks columns indicates parts supplied by PAVCSG.
·
Reference for O/I book languages are as follows:
Ar: Arabic Du: Dutch It: Italian Sp: Spanish
Cf: Canadian French En: English Ko: Korean Sw: Swedish
Cz: Czech Fr: French Po: Polish Co: Traditional Chinese
Da: Danish Ge: German Ru: Russian Cn: Simplified Chinese
Pe: Persian Ur: Ukraine
87
SA-PM33EE
