Panasonic SA-PM33EE - Replacement Parts List - Traverse Deck Parts; Replacement Parts List - Integrated Circuits

Ref.
No.
Part No. Part Name & Description Remarks
134 REM0120 CAP MOTOR ASS’Y [M]
135 RHD26022-1 MOTOR SCREW [M]
136 XTW2+5LFJ HEAD BLOCK UNIT SCRE [M]
137 XTW26+10SFJ SUB-CHASSIS SCREW [M]
138 XYC2+JF17FJ PCB EARTH SCREW [M]
139 RFKJSTR280PP CHASSIS ASS’Y [M]
TRAVERSE DECK
301 RAE0157Z-V TRAVERSE W/O PCB [M]
302 RDG0455 TRAVERSE GEAR (A) [M]
303 RDG0456-1 TRAVERSE GEAR (B) [M]
304 RFKNCT100 TRAVERSE BASE ASS’Y [M]
304-1 RDG0457 LOAD GEAR (A) [M]
304-10 RXQ0632 TRAVERSE MOTOR UNIT [M]
304-2 RDG0458 LOAD GEAR (B) [M]
304-3 RDG0459 LOAD GEAR (C) [M]
304-4 RME0369 PRESS SPRING [M]
304-5 RME0291 LOCK SPRING [M]
304-6 RML0551 TRIGGER LEVER [M]
304-7 RML0552 LOCK LEVER [M]
304-8 RMM0219 STOPPER [M]
304-9 XQN17+C28FJ SCREW [M]
305 RDG0460-2 CAM GEAR [M]
306 RDG0461 DRIVE GEAR [M]
307 RGQ0254-K2 TRAY [M]
308 RHM0001 MAGNET [M]
309 RMB0603 FLOATING SPRING [M]
310 RME0288 CENTERING SPRING [M]
311 RFKNXED50-S CLAMPER HOLDER ASS’Y [M]
312 RMG0510-K FLOATING RUBBER (A) [M]
313 RMG0511-K FLOATING RUBBER (B) [M]
314 RMK0422-6 MECHA CHASSIS [M]
315 RMM0218-1 TRAVERSE DRIVE RACK [M]
316 RHD30083-1 CAM. GEAR SCREW [M]
317 RMR1223-K1 CLAMP PLATE [M]
318 RMR1242-X2 FIXTURE [M]
319 XTN2+6GFJ SCREW [M]
320 RXQ0999 OPU UNIT [M]
321 SNSD38-1 SCREW [M]
PRINTED CIRCUIT BOARD
REPV0092B DECK P.C.B. / TAPE EJECT
P.C.B.
[M]
(RTL)
REPV0089A MAIN P.C.B. / PANEL P.C.B. /
HEADPHONE P.C.B.
[M]
(RTL)
REPV0090A TUNER EXTENT P.C.B. /
TRANSFORMER P.C.B. / POWER
P.C.B. / SPEAKER TERMINAL
P.C.B.
[M]
(RTL)
REPX0321H DECK MECHANISM P.C.B. [M]
(RTL)
REPV0082A CD SERVO P.C.B. [M]
(RTL)
INTEGRATED CIRCUITS
IC300 AN17831A IC POWER AMP [M]
IC700 C0ABBB000297 IC DUAL OP-AMP [M]
IC800 C1BB00000732 IC ASP [M]
IC801 C1BB00000987 IC RDS [M]
IC802 C0DBZGC00067 IC 3.3V REGULATOR [M]
IC803 MN101C49GHD IC MICROPROCESSOR [M]
IC900 C0HBB0000057 IC FL DRIVER [M]
IC971 CNB13030R2AU IC PHOTO INTERRUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SWITCH [M]
IC1001 AN7326K IC P/B REC AMP [M]
IC7001 MN6627954MA IC SERVO PROCESSOR/DIGITAL
SIGNAL PROCESSOR/DIGITAL
FILTER D/A CONVERTER
[M]
IC7002 BA5948FPE2 IC 4 CH DRIVE [M]
TRANSISTORS
Ref.
No.
Part No. Part Name & Description Remarks
Q221 B1ABGC000001 TRANSISTOR [M]
Q222 B1ABGC000001 TRANSISTOR [M]
Q421 B1ABGC000001 TRANSISTOR [M]
Q422 B1ABGC000001 TRANSISTOR [M]
Q500 B1GCCFGA0006 TRANSISTOR [M]
Q501 B1AACF000063 TRANSISTOR [M]
Q503 B1BCCG000002 TRANSISTOR [M]
Q504 B1AACF000063 TRANSISTOR [M]
Q505 B1AAJC000019 TRANSISTOR [M]
Q507 B1AAJC000019 TRANSISTOR [M]
Q530 2SD0592ARA TRANSISTOR [M]
Q600 B1AACF000063 TRANSISTOR [M]
Q601 2SC3940ARA TRANSISTOR [M]
Q602 KRC102MTA TRANSISTOR [M]
Q603 2SB0621AHA TRANSISTOR [M]
Q750 B1GDCFGG0026 TRANSISTOR [M]
Q751 B1GBCFJJ0044 TRANSISTOR [M]
Q801 B1GBCFGG0030 TRANSISTOR [M]
Q802 B1GBCFGG0030 TRANSISTOR [M]
Q803 B1GBCFJJ0044 TRANSISTOR [M]
Q804 B1GBCFNN0038 TRANSISTOR [M]
Q807 B1GBCFGJ0016 TRANSISTOR [M]
Q808 B1GBCFGJ0016 TRANSISTOR [M]
Q1101 B1ABGC000005 TRANSISTOR [M]
Q1201 B1ABGC000005 TRANSISTOR [M]
Q1302 B1GDCFJJ0002 TRANSISTOR [M]
Q1303 B1GBCFGH0001 TRANSISTOR [M]
Q1304 B1GDCFGH0002 TRANSISTOR [M]
Q1309 B1AAGC000006 TRANSISTOR [M]
Q1310 B1AAGC000006 TRANSISTOR [M]
Q1312 B1ABCF000011 TRANSISTOR [M]
Q1314 B1GDCFGH0002 TRANSISTOR [M]
Q1315 B1ACKD000006 TRANSISTOR [M]
Q1316 2SD09650RA TRANSISTOR [M]
Q1317 B1ABGC000005 TRANSISTOR [M]
Q7601 B1ADCF000001 TRANSISTOR [M]
DIODES
D380 B0AACK000004 DIODE [M]
D501 B0EAMM000038 DIODE [M]
D502 B0EAMM000038 DIODE [M]
D504 B0EAMM000038 DIODE [M]
D505 B0EAMM000038 DIODE [M]
D506 B0BA8R200005 DIODE [M]
D508 B0BA5R600016 DIODE [M]
D512 B0BA9R600002 DIODE [M]
D525 B0EAKM000117 DIODE [M]
D526 B0EAKM000117 DIODE [M]
D527 B0EAKM000117 DIODE [M]
D600 B0AACK000004 DIODE [M]
D602 B0EAKM000117 DIODE [M]
D603 B0EAKM000117 DIODE [M]
D604 B0EAKM000117 DIODE [M]
D605 B0EAKM000117 DIODE [M]
D606 B0EAKM000117 DIODE [M]
D607 B0BA6R800007 DIODE [M]
D608 B0AACK000004 DIODE [M]
D609 B0EAKM000117 DIODE [M]
D610 B0BA02600017 DIODE [M]
D611 B0EAKM000122 DIODE [M]
D750 B0ACCK000005 DIODE [M]
D751 B0ACCK000005 DIODE [M]
D802 B0ACCK000005 DIODE [M]
D803 B0ACCE000003 DIODE [M]
D804 B0ACCE000003 DIODE [M]
D805 B0ACCE000003 DIODE [M]
D806 B0ACCE000003 DIODE [M]
D807 B0ACCK000005 DIODE [M]
D900 B0BC5R600003 DIODE [M]
D906 B3AAA0000489 DIODE [M]
D971 MA2C16500E DIODE [M]
D1301 B0ACCK000005 DIODE [M]
88
SA-PM33EE
