Panasonic SA-PM33EE - Replacement Parts List - Transistors and Diodes

Ref.
No.
Part No. Part Name & Description Remarks
D7650 MAZ80560ML DIODE [M]
VARIABLE RESISTORS
VR900 EVEJ1CF3024B VR VOLUME JOG [M]
SWITCHES
S780 K0F111E00093 SW CD OPEN [M]
S900 EVQ21405RJ SW STOP/-DEMO [M]
S901 EVQ21405RJ SW CD [M]
S902 EVQ21405RJ SW TAPE [M]
S903 EVQ21405RJ SW TUNER/BAND [M]
S904 EVQ21405RJ SW FF/TUNE UP [M]
S905 EVQ21405RJ SW REW/TUNE DWN [M]
S906 EVQ21405RJ SW POWER [M]
S907 EVQ21405RJ SW CD OPEN/CLOSE [M]
S908 EVQ21405RJ SW BASS/TREBLE [M]
S909 EVQ21405RJ SW REC [M]
S910 EVQ21405RJ SW MUSIC PORT [M]
S971 K0J1BB000017 SW MODE [M]
S972 K0J1BB000021 SW HALF [M]
S973 K0J1BB000021 SW CR02 [M]
S975 K0J1BB000021 SW RECINH_F [M]
S1000 EVQ21405RJ SW TAPE EJECT [M]
S7201 RSH1A048-A SW RESET [M]
CONNECTORS
CN10 K1KB10B00042 10P CONNECTOR [M]
CN401A K1KA10AA0031 10P CONNECTOR [M]
CN501A K1KB04A00035 4P CONNECTOR [M]
CN501B K1KA04BA0125 4P CONNECTOR [M]
CN503A K1KA09AA0031 9P CONNECTOR [M]
CN503B K1KB09B00013 9P CONNECTOR [M]
CN504A K1MP04A00003 4P CONNECTOR [M]
CN505B K1KA08AA0319 8P CONNECTOR [M]
CN508A K1KA13AA0031 13P CONNECTOR [M]
CN508B K1KB13B00017 13P CONNECTOR [M]
CN801 K1MN17AA0004 17P CONNECTOR [M]
CN803A K1KA09AA0031 9P CONNECTOR [M]
CN803B K1KB09B00013 9P CONNECTOR [M]
CN804 K1MN19A00027 19P CONNECTOR [M]
CN808A K1KA13AA0031 13P CONNECTOR [M]
CN808B K1KB13B00017 13P CONNECTOR [M]
CN900B K1MP05A00004 5P CONNECTOR [M]
CN901A K1MN15A00049 15P FFC CONNECTOR [M]
CN901B K1MN15A00049 15P FFC CONNECTOR [M]
CN1303 K1MN19BA0005 19P CONNECTOR [M]
CN7001 K1MN16B00154 16P CONNECTOR [M]
CN7002 K1MN17B00032 17P CONNECTOR [M]
CP800 REXX0230-2 2P CONNECTOR (MAIN TO CR120) [M]
CP1301 K1MY05AA0043 5P CONNECTOR [M]
CP1902 K1KA09BA0153 9P CONNECTOR [M]
CS971 RJU071H09M1 9P CONNECTOR [M]
COILS & TRANSFORMERS
L203 J0JBC0000019 CHIP INDUCTOR [M]
L204 G0C3R3JA0027 COIL [M]
L300 G0AR76Y00002 CHOKE COIL [M]
L301 G0AR76Y00002 CHOKE COIL [M]
L302 G0AR76Y00002 CHOKE COIL [M]
L303 G0AR76Y00002 CHOKE COIL [M]
L600 G0B371HA0005 LINE FILTER [M]
L801 J0JKB0000020 EMI BEAD CORE [M]
L802 J0JKB0000020 EMI BEAD CORE [M]
L803 J0JKB0000020 EMI BEAD CORE [M]
L804 G0C3R3JA0027 COIL [M]
L805 G0C3R3JA0027 COIL [M]
L806 G0A200D00002 RF CHOKE COIL [M]
Ref.
No.
Part No. Part Name & Description Remarks
L807 G0A200D00002 RF CHOKE COIL [M]
L810 G0C101JA0027 COIL [M]
L811 G0C101JA0027 COIL [M]
L812 J0JKB0000020 EMI BEAD CORE [M]
L901 G0C3R3JA0027 COIL [M]
L1301 G2ZZ00000024 BIAS OCS COIL [M]
L1302 G0C470JA0052 RF CHOKE COIL [M]
T600 RTP1H3E002 BACK-UP TRANSFORMER [M]
T601 G4CYAYY00063 POWER TRANSFORMER [M]
COMPONENT COMBINATIONS
Z401 ENG07811QF TUNER PACK [M]
Z600 ERZV10V511CS ZENER [M]
Z901 B3RAD0000125 REMOTE SENSOR [M]
RELAY
RL600 K6B1ADA00011 RELAY [M]
OSCILLATORS
X801 H4Z8004AA001 CERAMIC RESONATOR [M]
X802 H0A327200100 CRYSTAL [M]
X803 H0H433400002 CRYSTAL [M]
X7201 H2B169500005 CRYSTAL [M]
DISPLAY TUBE
FL900 A2BB00000157 FL DISPLAY [M]
FUSE
F1 K5D631BLA012 FUSE [M]
FUSE HOLDERS
FC600 EYF52BCY FUSE CLIP [M]
FC601 EYF52BCY FUSE CLIP [M]
FUSE PROTECTOR
FP352 K5G502A00039 FUSE PROTECTOR [M]
JACKS
JK303 K2HC1YYA0003 JK AUX [M]
JK501 K4BC04B00086 JK RED/BLACK SPEAKER [M]
JK600 K2AA2B000015 JK AC INLET [M]
JK900 K2HC103A0024 JK HP [M]
EARTH TERMINAL
ZJ01 SNE1004-3 EARTH TERMINAL [M]
CHIP JUMPERS
W7001 ERJ6GEY0R00V CHIP JUMPER [M]
W7002 ERJ6GEY0R00V CHIP JUMPER [M]
W7003 ERJ6GEY0R00V CHIP JUMPER [M]
W7004 ERJ3GEY0R00V CHIP JUMPER [M]
W7005 ERJ3GEY0R00V CHIP JUMPER [M]
W7006 ERJ6GEY0R00V CHIP JUMPER [M]
W7007 ERJ6GEY0R00V CHIP JUMPER [M]
W7008 ERJ6GEY0R00V CHIP JUMPER [M]
W7009 ERJ3GEY0R00V CHIP JUMPER [M]
W7010 ERJ3GEY0R00V CHIP JUMPER [M]
W7011 ERJ3GEY0R00V CHIP JUMPER [M]
W7012 ERJ3GEY0R00V CHIP JUMPER [M]
W7013 ERJ3GEY0R00V CHIP JUMPER [M]
W7014 ERJ3GEY0R00V CHIP JUMPER [M]
W7015 ERJ3GEY0R00V CHIP JUMPER [M]
89
SA-PM33EE
