Panasonic SA-PM33EE - Voltage Measurement - Panel PCB; Voltage Measurement - Power PCB

14.1.3. Panel P.C.B.
Ref No.
MODE 1 234567891011121314151617181920
CD PLAY 0 0 0 0 2.8 1.6 0.1 0.2 2.8 0 0 0 4.9 -22.7 -22.7 -22.7 -20.6 -22.7 -20.6 -22.7
STANDBY 0 000000000 0 00-21.2-21.2-21.2-21.2-21.2-21.2-21.2
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -22.7 -22.7 -20.6 -20.6 -22.7 -22.7 -22.7 -22.7 -20.6 -23.2 -20.8 -20.8 -20.8 -20.8 -20.8 -20.9 -20.9 -20.9 -20.9 -20.9
STANDBY -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2 -21.2
Ref No.
MODE 41 42 43 44
CD PLAY -20.9 -20.9 4.9 0
STANDBY -21.2 -21.2 0 0
PANEL P.C.B
IC900
IC900
IC900
14.1.4. Power P.C.B.
Ref No.
MODE 1 23456789101112
CD PLAY 23.4 11.4 0 11.4 4.6 0 0 0 4.2 11.4 0 11.4
STANDBY 2.90.300.3000000.300.3
Ref No.
MODE E C B E C B E C B E C B E C B
CD PLAY 23.3 20 23.3 5 20 5.6 20.8 9.7 20.3 5 9.6 5.6 4.8 7.5 5.5
STANDBY 4.3 2.4 4.3 2.4 2.5 3.2 2.9 0.2 2.5 2.4 0.2 0.1 0 0 0
Ref No.
MODE E C B E C B
CD PLAY 7.5 9.7 8.2 8.8 9.7 9.5
STANDBY 0 0.1 0.1 0 0.1 0.1
Q507 Q530
POWER P.C.B
IC300
Q500 Q501 Q503 Q504 Q505
14.1.5. Transformer P.C.B.
Ref No.
MODE E C B E C B E C B E C B
CD PLAY 0 0.2 0.8 5.6 8.5 6.3 0 2.6 1.8 -23 -31.8 -23.7
STANDBY 0 5.7 0 5.7 10 6.9 0 2.7 2 -21 -21.4 -21.4
TRANSFORMER P.C.B
Q600 Q601 Q602 Q603
