Panasonic SA-PM33EE - IC803 Microprocessor Terminal Functions (Continued)

Pin No. Mark I/O Function
85 N.C. - No Connection
86 N.C. - No Connection
87 N.C. - No Connection
88 N.C. - No Connection
89 N.C. - No Connection
90 MP1 - No Connection
91 MP2 - No Connection
92 CRTIMER I/O CR Timer
93 N.C. - No Connection
94 S/W RST - Switch Reset
95 VREF - - D/A Converter Reference GND
96 VOL_JOG1 I Jog Input 1
97 VOL_JOG2 I Jog Input 2
98 CLOSE_L O CD Tray Close Control (Active
L)
99 OPEN_H O CD Tray Open Control (Active
H)
100 VREF + - D/A Converter Reference
Voltage
