47
References
RQT5377
SPEAKER SECTION
[Front\speakers\SB-PM08]
Type 3 way, 3 speaker
Speakers
Super woofer 14 cm (5
1
/2") cone type
Woofer 10 cm (4") cone type
Tweeter 6 cm (2
3
/8") cone type
Impedance
HIGH 6
LOW 6
Input power
HIGH 30 W (Music)
LOW 30 W (Music)
Output sound pressure level 86 dB/W (1.0 m)
Cross over frequency 110 Hz, 6 kHz
Frequency range 43 Hz–22 kHz (j16 dB)
52 Hz–20 kHz (j10 dB)
Dimensions (WtHtD) 179k261k312 mm
(7
1
/16"k10
9
/32"k12
9
/32")
Mass 3.7 kg (8.2 Ib.)
[Center\speaker\SB-PC80]
Type 1 way, 1 speaker
Speaker
Full range 8 cm (3
1
/8") cone type
Impedance 6
Input power 60 W (Music)
Output sound pressure level 79 dB/W (1.0 m)
Frequency range 80 Hz–22 kHz (j16 dB)
110 Hz–20 kHz (j10 dB)
Dimensions (WtHtD) 88k158k105 mm
(3
15
/32"k6
7
/32"k4
1
/8")
Mass 0.8 kg (1.8 Ib.)
[Surround\speakers\SB-PS80]
Type 1 way, 1 speaker
Speaker
Full range 8 cm (3
1
/8") cone type
Impedance 6
Input power 60 W (Music)
Output sound pressure level 79 dB/W (1.0 m)
Frequency range 80 Hz–22 kHz (j16 dB)
110 Hz–20 kHz (j10 dB)
Dimensions (WtHtD) 88k158k105 mm
(3
15
/32"k6
7
/32"k4
1
/8")
Mass 0.7 kg (1.5 Ib.)
GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 85 W
Standby Approx. 0.3 W
Dimensions (WtHtD) 250k131k323 mm
(9
27
/32"k5
5
/32"k12
23
/32")
Mass 5.2 kg (11.5 Ib.)
Notes:
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
AMPLIFIER SECTION
Input sensitivity
AUX 250 mV
Input impedance
AUX 30 k
FM TUNER SECTION
Frequency range 87.9–107.9 MHz (200 kHz step)
87.5–108.0 MHz (100 kHz step)
Sensitivity 16.3 dBf (1.8 ¬V, IHF’58)
Antenna terminals 75 (unbalanced)
AM TUNER SECTION
Frequency range 520–1710 kHz (10 kHz step)
Sensitivity
S/N 20 dB at 1000 kHz 500 ¬V/m
DISC SECTION
Disc
DVD-Video 8 cm/12 cm single-sided, single-layer
8 cm/12 cm single-sided, double-layer
8 cm/12 cm double-sided, double-layer
(One layer per side)
Video CD/CD 8 cm/12 cm
Video
Signal system NTSC
Output level Composite video 1 Vp-p (75 )
S-VIDEO Y 1 Vp-p (75 )
S-VIDEO C 0.286 Vp-p (75 /NTSC)
Audio
Sampling frequency
CD 44.1 kHz
DVD 48 kHz/96 kHz
Decoding 16/20/24 bit linear
Wow and flutter Below measurable limit
Digital filter 8 fs
D/A converter Delta-sigma DAC
Pick up
Beam Source Semiconductor Laser
Wavelength 665 nm
Specifications
pm08.p33-48.p65 4/4/00, 9:22 AM47
